Service Manual: Viewsonic Ve710B-4 Ve710S-4

Service Manual
ViewSonic VE710b-4
VE710s-4
Model No. VS10047
17 Color TFT LCD Display
(VE710s-4_VE710b-4_SM Rev. 1a Jun. 2006)

ViewSonic 381 Brea Canyon Road, Walnut, California 91789 USA (800) 888-8583
Copyright
Copyright 2006 by ViewSonic Corporation. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of ViewSonic
Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to
the contents hereof and specifically disclaims any warranty of merchantability or fitness for any
particular purpose. Further, ViewSonic reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation of ViewSonic to notify any
person of such revision or changes.
Trademarks
Opt quest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.
Revision History
Revision
1a
SM Editing Date
06/27/2006
ViewSonic Corporation
ECR Number
Description of Changes
Initial Release
Editor
J. Chang
i
Confidential - Do Not Copy
VE710s-4_VE710b-4
TABLE OF CONTENTS
1.
Precautions and Safety Notices
2.
Specification
3.
Front Panel Function Control Description
4.
Circuit Description
11
5.
Adjustment Procedure
19
6.
Troubleshooting Flow Chart
39
7.
Recommended Spare Parts List
43
8.
Exploded Diagram and Exploded Parts List
63
9.
Block Diagram
68
10. Schematic Diagrams
71
11. PCB Layout Diagrams
81
ii
VE710s-4_VE710b-4
1. Precautions and Safety Notices (VE710s-4/VE710b-4)

1.1. SAFETY PRECAUTIONS
This monitor is manufactured and tested on a ground principle that a user's safety comes first. However,
improper use or installation may cause damage to the monitor as well as to the user. Carefully go over the
following WARNINGS before installing and keep this guide handy.
WARNINGS:
u This monitor should be operated only at the correct power sources indicated on the label on the rear end of
the monitor. If you're unsure of the power supply in your residence, consult your local dealer or power
company.
u Use only the special power adapter that comes with this monitor for power input.
u Do not try to repair the monitor your self as it contains no user-serviceable parts. This monitor should only
be repaired by a qualified technician.
u Do not remove the monitor cabinet. There is high-voltage parts inside that may cause electric shock to
human bodies, even when the power cord is unplugged.
u Stop using the monitor if the cabinet is damaged. Have it checked by a service technacian.
u Put your monitor only in a clean, dry environment. If it gets wet, unplug the power cable immediately and
consult your service technician.
u Always unplug the monitor before cleaning it. Clean the cabinet with a clean, dry cloth. Apply
non-ammonia based cleaner onto the cloth, not directly onto the glass screen.
u Keep the monitor away from magnetic objects, motors, TV sets, and transformer.
u Do not place heavy objects on the monitor or power cord.
1.2. PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in this chassis have special safety visual inspections and the protection
afforded by them cannot necessarily be obtained by using replacement components rated for higher voltages,
wattage, etc. Before replacing any of these components read the parts list in this manual carefully. The use of
substitute replacement parts which do not have the same safety characteristics as specified in the parts list may
create shock, fire, or other hazards.
1.3. SERVICE NOTES

1. When replacing parts or circuit boards, clamp the lead wires around terminals before soldering.
2. When replacing a high wattage resistor (more than 1W of metal oxide film resistor) in circuit board, keep the
resistor about 5mm away from circuit board.
3. Keep wires away from high voltage, high temperature components and sharp edges.
4. Keep wires in their original position so as to reduce interference.
5. Usage of this product please refer to also user's manual.
1
VE710s-4_VE710b-4
2. Specification (VE710s-4/VE710b-4)
2.1. PRODUCT SPECIFICATIONS

LCD Panel
17.0" TFT
Power Management
Energy Star compliant VESA

DPMS compatible
< 1W
Displayable Resolution
SXGA 1280 1024 (max.)
Pixel Dimension
0.264(H) 0.264(V)mm
LCD Display Color
262K Color. (6bit)
Viewing Angle
CR10
Horizontal: 140 deg
Vertical: 130 deg
Contrast Ratio
450 : 1 (typ.) 360:1 (min.)
Brightness
230 cd/ m (min.)
300 cd/m (typ.)

Response Time
CPT Panel:
CLAA170EA08Q (8ms) Tr: 2 ms Tf: 6 ms (typ.) Tr: 7 ms Tf: 11 ms (max.)
CMO Panel:
M170E5-L09 (8ms) Tr: 2 ms Tf: 6 ms (typ.), Tr: 7 ms Tf: 11 ms (max.)
Active Display Area
337.9mm(H) 270.3mm(V)
Temperature
Operating: 0C ~ +40C
Storage: -20C ~ +60C
Compliance
UL, CUL, TV, CE, FCC, VCCI, BSMI,CCC, Energy Star.
Power
Input Voltage: 100~240 Vac

Consumption: 35 Watts (Max.)
2.2. FACTORY SUPPORTING MODES

Primary Preset:
VESA 1280 x 1024 @ 60Hz
Look up table timing:
1. 640 x 350 @ 70Hz, 31.5kHz

2. 640 x 480 @ 60Hz, 31.5kHz
3. 640 x 480 @ 67Hz, 35.0kHz
4. 640 x 480 @ 75Hz, 37.5kHz
5. 640 x 480 @ 72Hz, 37.9kHz
6. 640 x 480 @ 85Hz, 43.27kHz
7. 720 x 400 @ 70Hz, 31.5kHz
8. 800 x 600 @ 56Hz, 35.1kHz
9. 800 x 600 @ 60Hz, 37.9kHz
2
VE710s-4_VE710b-4
10. 800 x 600 @ 75Hz, 46.9kHz

11. 800 x 600 @ 72Hz, 48.1kHz
12. 800 x 600 @ 85Hz, 53.7kHz
13. 832 x 624 @ 75Hz, 49.7kHz
14. 1024 x 768 @ 60Hz, 48.4kHz
15. 1024 x 768 @ 70Hz, 56.5kHz
16. 1024 x 768 @ 72Hz, 58.1kHz
17. 1024 x 768 @ 75Hz, 60.0kHz
18. 1024 x 768 @ 85Hz, 68.67kHz
19. 1280 x 1024 @ 60Hz, 63.4kHz
20. 1280 x 1024 @ 75Hz, 79.97kHz
21. 1280x720 @ 60Hz, 45kHz
2.3. D-SUB CONNECTOR
D-SUB 15 PIN CONNECTOR
2
6
11
3
7
12
4
8
13
5
9
14
10
15
1.R
6.GND
11.NC
2.G
7.GND
12.SDA
3.B
8.GND
13.H.SYNC
4.NC
9. +5V
14.V.SYNC
5.GND
10.GND 15.SCL
SIGNAL LEVEL
CONNECTOR
SIGNAL
DESCRIPTION
RED
0.7vp-p(VIDEO)
GREEN
0.7vp-p(VIDEO)
BLUE
0.7vp-p(VIDEO)
H/SYNC
TTL positive or negative
V/SYNC
TTL positive or negative
SDA
DDC1/2B
TTL
SCL
DDC1/2B
TTL
3
VE710s-4_VE710b-4
3. Front Panel Function Control Description

VE710s-4/VE710b-4
Main Menu
With OnView controls
Front Control Panel

shown below in detail
Displays the control

screen for the highlighted
control.
Also toggles between two
controls on some
screens.
Also a shortcut to Auto
Image Adjust.
Scrolls through menu options and

adjusts the displayed control.
Power light
Green = ON
Orange = Power Saving
Displays the Main Menu

or exits the control screen
and saves adjustments.
Also a shortcut to display the

Contrast adjustment control
screen.
Power
On/Off
4
VE710s-4_VE710b-4
Do the following to adjust the screen image:

1
To display the Main Menu, press button [1].

Main Menu
AUTO
SET
Auto Adjust
Contrast/Brightness
Color Adjust
Information
Image Adjust
Setup Menu
Memory Recall
1:EXIT
2:SELECT
NOTE: All OnView menus and adjustment screens disappear automatically

after about 15 seconds. This time period is adjustable through the Setup
menu and the OSD timeout control described on page 11.
2
3
To highlight a control you want to adjust, press I or J to scroll up or down

the Main Menu.
To select the highlighted control, press button [2]. A control screen appears
like the example shown below.
The line at the
bottom of the
screen tells you
what you can do
next: Exit or Select
the control that is
highlighted.
Contrast
1:EXIT
4
5
2:
Brightness
To adjust the control, press the up I or down J buttons.

To save the adjustments and exit the menu, press button [1] twice.
The following tips may help you optimize your display:

Adjust your computer's graphic card so that it outputs a video signal 1280 x
1024 @ 60 Hz to the LCD dislay. (Look for instructions on changing the
refresh rate in your graphic card's user guide.)
If necessary, make small adjustments using H. POSITION and V. POSITION
until the screen image is completely visible. (The black border around the
edge of the screen should barely touch the illuminated active area of the
LCD dislay.)
5
VE710s-4_VE710b-4
Main Menu Controls

Adjust the menu items shown below by using the up Iand down Jbuttons.
Control
Explanation
Auto Adjust automatically sizes, centers, and fine tunes the
video signal to eliminate waviness and distortion.

Press the [2] button to obtain a sharper image.
NOTE: Auto Adjust works with most common video cards. If
this function does not work on your LCD dislay, then lower the
video refresh rate to 60 Hz and set the resolution to its pre-set
value.
Contrast adjusts the difference between the image background
(black level) and the foreground (white level).

Brightness adjusts background black level of the screen image.
Color Adjust provides several color options: preset color
temperatures and User which allows you to adjust red (R), green
(G), and blue (B). The factory setting for this product is 6500K
(6500 Kelvin).
sRGB sRGB is quickly becoming the industry standard for color
management, with support being included in many of the latest

applications. Enabling this setting allows the LCD display to
more accurately display colors the way they were originally
intended. Enabling the sRGB setting will cause the Contrast and
Brightness adjustments to be disabled.
9300K Adds blue to the screen image for cooler white (used
in most office settings with fluorescent lighting).

6500K Adds red to the screen image for warmer white and
richer red. Default setting.
5400K Adds green to the screen image for a darker color.
6
VE710s-4_VE710b-4
Control
Explanation
User Individual adjustments for red, green, and blue.
To select color (R, G or B) press button [2].

To adjust selected color, press I or J.
When you are finished making all color adjustments, press
button [1] twice.
1
2
3
Information displays the timing mode (video signal input)
coming from the graphics card in your computer. See your

graphic cards user guide for instructions on changing the
resolution and refresh rate (vertical frequency).
VESA 1280 x 1024 @ 60 Hz (recommended) means that the
resolution is 1280 x 1024 and the refresh rate is 60 Hertz.
Image Adjust
Image Adjust
H./V. Position
H. Size
Fine Tune
Sharpness
1:EXIT
2:SELECT
The Image Adjust controls are explained below:

H./V. Position adjusts horizontal and vertical position of the
screen image. You can toggle between Horizontal and Vertical

by pressing button [2]. Horizontal moves the screen image to
the left or to the right. Vertical moves the screen image up and
down.
H. Size (Horizontal Size) adjusts the width of the screen image.
NOTE: Vertical size is automatic with your LCD dislay.
7
VE710s-4_VE710b-4
Control
Explanation
Fine Tune sharpens focus by aligning the illuminated text and/
or graphic characters.
NOTE: Try the Auto Adjust (see page 9) before using the Fine
Tune control.
Sharpness adjusts the clarity and focus of the screen image.
Setup Menu displays the menu shown below.
The Setup Menu controls are explained below.

Language Select allows you to choose the language used in
the menus and control screens.

Resolution Notice advises the optimal resolution to use.
OSD
OSD Position allows you to move the on-screen display menus

and control screens.
OSD Timeout sets the length of time an on-screen display
screen is displayed. For example, with a 15 second setting, if

a control is not pushed within 15 seconds, the display screen
disappears.
8
VE710s-4_VE710b-4
Control
OSD
Explanation
OSD Background allows you to turn the On-Screen display

background on or off. This means that while making adjustments
from the OSD control screens you can also view open software
applications, or the Windows desktop.
Memory Recall returns adjustments to the original factory
settings if the display is operating in a factory Preset Timing

Mode listed in this user guide.
9
VE710s-4_VE710b-4
Short Cut Key
Function Key : 5 Keys !

[1]
[2]
[
] or [
]

Main Menu
Auto Image Adjust
to immediately activate Contrast menu.
It should be change to Brightness OSD
by push button [2].
[
] + [
]
recall Contrast or Brightness while in

the Contrast or Brightness adjustment,
or recall both of Contrast and
Brightness when the OSD is not open.
[1] + [2]
toggle 720x400 and 640x400 mode when

input 720x400 or 640x400 mode.
[1] + [
] + [
]
White Balance.
(Keep pushing 5 sec)
[1] + [
]
Power Lock
[1] + [
]
OSD Lock
10
VE710s-4_VE710b-4
4. Circuit Description (VE710s-4/VE710b-4 M-star Scaler)

A. Scaling controller
The ADC is to convert RGB analog signal to digital signal that scaling chip can acknowledge.
The HSYNC input receives a logic signal and provides the frequency reference for pixel clock generation.
The scaling IC is to converts the input signal ranging from VGA to SXGA into SXGA resolution that panel can
acknowledge.
GENERAL DESCRIPTION
The MST8116A is a high performance, and fully integrated graphics processing IC solution for LCD monitors
with resolutions up to SXGA. It is configured with an integrated triple -ADC/PLL, a high quality scaling engine, an
on-screen display controller, a built -in output clock generator, a panel timing controller (TCON), and RSDS
display interface. To further reduce system costs, the MST8116A also integrates intelligent power management
control capability for green-mode requirements and spread-spectrum support for EMI management.
PIN DESCRIPTION
CPU Interface
Pin Name Pin Type Function Pin
HWRESET Schmitt Trigger Input
w/ 5V-tolerant Hardware reset; active high 32
CS Input w/ 5V-tolerant 3 Wire Serial Bus Chip Select; active high 69
SDA I/O w/ 5V-tolerant 3 Wire Serial Bus Data; 4mA driving strength 70
SCL Input w/ 5V-tolerant 3 Wire Serial Bus Clock 71
INT Output CPU interrupt; 4mA driving strength 72
Analog Interface
HSYNC0 Schmitt Trigger Input
w/ 5V-tolerant Analog HSYNC input 37
VSYNC0 Schmitt Trigger Input
w/ 5V-tolerant Analog VSYNC input 38
REFP Internal ADC top de-coupling pin 66
REFM Internal ADC bottom de-coupling pin 67
RIN0 Analog Input Analog red input 63
RIN0M Analog Input Reference ground for analog red input 62
SOGIN0 Analog Input Sync-on-green input 61
GIN0 Analog Input Analog green input 60
GIN0M Analog Input Reference ground for analog green input 59
BIN0 Analog Input Analog blue input 58
BIN0M Analog Input Reference ground for analog blue input 57
REXT External resistor 390 ohm to AVDD 52
RSDS Interface
CLKAP Output A-Link Positive RSDS Differential Clock Output fromOdd Channel 118
CLKAN Output A-Link Negative RSDS Differential Clock Output fromOdd Channel 119
CLKBP Output B-Link Positive RSDS Differential Clock Output fromEven Channel 120
CLKBN Output B-Link Negative RSDS Differential Clock Output fromEven Channel 121
BA[3:1]P Output A-Link Positive RSDS Differential Data Output fromOdd Channel 92, 90, 88
BA[3:1]N Output A-Link Negative RSDS Differential Data Output fromOdd Channel 93, 91, 89
GA[3:1]P Output A-Link Positive RSDS Differential Data Output fromOdd Channel 102, 100, 98
GA[3:1]N Output A-Link Negative RSDS Differential Data Output fromOdd Channel103, 101,99
RA[3:1]P Output A-Link Positive RSDS Differential Data Output fromOdd Channel 112, 110, 108
RA[3:1]N Output A-Link Negative RSDS Differential Data Output fromOdd Channel 113, 111, 109
BB[3:1]P Output B-Link Positive RSDS Differential Data Output fromEven Channel 4, 128, 124
BB[3:1]N Output B-Link Negative RSDS Differential Data Output fromEven Channel 5, 1, 125
GB[3:1]P Output B-Link Positive RSDS Differential Data Output fromEven Channel 14, 12, 8
GB[3:1]N Output B-Link Negative RSDS Differential Data Output fromEven Channel 15, 13, 9
RB[3:1]P Output B-Link Positive RSDS Differential Data Output fromEven Channel 24, 22, 16
RB[3:1]N Output B-Link Negative RSDS Differential Data Output fromEven Channel 25, 23, 17
GPO[8:5] Output TCON GPO[8:5]; 4mA driving strength 29, 28, 30,31
GPO[4:0] Output w/ Pull-down TCON GPO[4:0]; 4~12mA driving strength programmable 79-83
OINV Output w/ Pull-down Resistor TCON Odd Channel Inversion; 4~12mA driving strength programmable 78
EINV Output w/ Pull-down Resistor TCON Even Channel Inversion; 4~12mA driving strength programmable 77
OSP Output w/ Pull-down Resistor TCON Odd Channel Start Pulse; 4~12mA driving strength programmable 76
ESP Output w/ Pull-down Resistor TCON Even Channel Start Pulse; 4~12mA driving strength programmable 75
GPIO Interface
11
VE710s-4_VE710b-4
GOUT1/PWM1 Output GOUT1/PWM1; 4mA driving strength 74

GOUT0/PWM0 Output GOUT0/PWM0; 4mA driving strength 73
Misc. Interface
BYPASS For External Bypass Capacitor 3
XIN Crystal Oscillator Input Xin 33
XOUT Crystal Oscillator Output Xout 34
Power Pins
AVDD 3.3V Power ADC Power 45, 51, 55, 65
AVSS Ground ADC Ground 39, 42, 48, 56,
64, 68
AVDD_PLL 3.3V Power PLL Power 53
AVSS_PLL Ground PLL Ground 54
AVDD_MPLL 3.3V Power MPLL Power 35
AVSS_MPLL Ground MPLL Ground 2, 36
VDDP 3.3V Power Digital Output Power 11, 21, 84, 94,
104, 114, 126
GNDP Ground Digital Output Ground 10, 20, 85, 95,
105, 115, 127
VDDC 2.5V Power Digital Core Power 18, 87, 97, 117
GNDC Ground Digital Core Ground 19, 86, 96, 116
No Connects
NC No Connect. Leave These Pins Floating.
6, 7, 26, 27, 40,
41, 43, 44, 46,
47, 49, 50, 106,
107, 122, 123
Resolution 8 Bits
DC ACCURACY
Differential Nonlinearity 0.5 +1.50/-1.0 LSB
Integral Nonlinearity 1 LSB
No Missing Codes Guaranteed
ANALOG INPUT
Input Voltage Range
Minimum 0.5 V p-p
Maximum 1.0 V p-p
Input Bias Current 1 uA
Input Full-Scale Matching 1.5 %FS
Brightness Level Adjustment 62 %FS
SWITCHING PERFORMANCE
Maximum Conversion Rate 165 MSPS
Minimum Conversion Rate 20 MSPS
HSYNC Input Frequency 15 200 kHz
PLL Clock Rate 20 162.5 MHz
PLL Jitter 500 ps p-p
Sampling Phase Tempco TBD ps/C
DIGITAL INPUTS
Input Voltage, High (VIH) 2.5 V
Input Voltage, Low (VIL) 0.8 V
Input Current, High (IIH) -1.0 uA
Input Current, Low (IIL) 1.0 uA
Input Capacitance 5 pF
DIGITAL OUTPUTS
Output Voltage, High (VOH) VDDP-0.1 V
Output Voltage, Low (VOL) 0.1 V
DYNAMIC PERFORMANCE
Analog Bandwidth, Full Power 250 MHz
Channel to Channel Matching 0.5% Full-Scale
3.3V Supply Voltages VVDD_33 -0.3 3.6 V
2.5V Supply Voltages VVDD_25 -0.3 2.75 V
Input Voltage (5V tolerant inputs) VIN5Vtol -0.3 5.0 V
Input Voltage (non 5V tolerant inputs) VIN -0.3 VVDD_33 V
B. MTV312M64
The MTV312M micro-controller is an 8051 CPU core embedded device especially tailored for CRT/LCD
Monitor applications. It includes an 8051 CPU core, 1024-byte SRAM, 14 built-in PWM DACs, VESA DDC interface, 4-channel A/D
converter, and a 64K-byte internal program Flash -ROM.
A CMOS output pin means it can sink and drive at least 4mA current. It is not recommended to use such
pin as input function.
A open drain pin means it can sink at least 4mA current but only drive 10~20uA to VDD. It can be used as input or output function and needs
12
VE710s-4_VE710b-4
an external pull up resistor.

A 8051 standard pin is a pseudo open drain pin. It can sink at least 4mA current when output is at low level, and drives at least 4mA current
for 160nS when output transits from low to high, then keeps driving at 100uA to maintain the pin at high level. It can be used as input or output
function. It needs an external pull up resistor when driving heavy load device.
POWER CONFIGURATION
The MTV312M can work on 5V or 3.3V power supply system.
In 5V power system, the VDD pin is connected to 5V power and the VDD3 needs an external capacitor, all
output pins can swing from 0~5V, input pins can accept 0~5V input range.
And ADC conversion range is 5V. However, X1 and X2 pins must be kept below 3.3V.
In 3.3V power system, the VDD and VDD3 are connected to 3.3V power, all output pins swing from 0~3.3V, HSYNC, VSYNC and open drain
pin can accept 0~5V input range, other pins must be kept below 3.3V. And the ADC conversion range is 3.3V.
C. INVERTER
In order to drive the CCFLs embedded in the panel module, there is a half bridge inverter to convert by the controller.
The input 12V up to hundreds of AC voltage output.
The inverter is formed by symmetric in order to drive the separate lamp modules.
The input stage consists of a PWM controller, half bridge inverter, and switching MOSFET to convert DC input into AC output.
The output stage consists of a tuning capacitor, coupling capacitor, transformer, push-pull MOSFET pair to boost AC output up to hundreds of
voltage.
And one resister is serial to lamp for output voltage feedback.
There are two signal to control the inverter which come from system.
Logic high level which send to I901 is turn on the inverter.
BRI signal control brightness by DC level which was integral from PWM signal.
13
VE710s-4_VE710b-4
Circuit Description (VE710s-4/VE710b-4 Realtek Scaler)

A. Scaling controller
General
l
l
l
l
l
l
l
l
Embedded dual DDC support DDC1, DDC2B,DDC/CI

Zoom scaling up and down
Embedded Pattern Generator
No external memory required.
Require only one crystal to generate all timing
Embedded reset control output
Embedded crystal output to MICROP
3 channels 8 bits PWM output, and selectable PWM clock frequency.
PIN DESCRIPTION
(I/O Legend: A= Analog , I=Input ,O=Output ,P=Power ,G=Ground)

ADC: 15 pins
Name
ADC_ GND
ADC_REFIO
ADC_VDD
BLUE+
BLUEADC_ GND
SOG/ADC_TEST
GREEN+
GREENADCB_VDD
RED+
RED_
ADC_GND
ADC_GND
ADC_VDD
AHS
AVS
I/O
AG
AP
AP
AI
AI
AG
AIO
AI
AI
AP
AI
AI
AG
AG
AP
AI
AI
Pin No
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Description
ADC ground
ADC band-gap voltage de-coupling
Analog power
Analog input from BLUE channel
Analog input ground from BLUE channel
ADC ground
SOG in/ADC test pin
Analog input from GREEN channel
Analog input ground from GREEN channel
Analog power
Analog input from RED channel
Analog input ground from RED channel
Analog ground
Analog ground
Analog power
Analog HS input
Analog VS input
PLL:8 pins
Name
XO
XI
DPLL GND
DPLL VDD
APLL VDD
PLL TEST1
PLL TEST2
I/O
AI
AO
AG
AP
AP
AIO
AIO
Pin No
1
2
3
4
5
6
7
APLL GND
AG
Description
Reference clock output
Reference clock input
Ground for digital PLL
Power for digital PLL
Power for multi-phase PLL
Test Pin 1 / IRQ#
Test Pin 2/Power-on-latch for crystal out
Frequency
Ground for multi-phase PLL
Note
1.20V
(3.3V)
(3.3V)
(3.3V)
(10), (4), (5)
(2), (4), (5)
Note
(3.3V)
(3.3V)
3.3V tolerance
14
VE710s-4_VE710b-4
Control Interface: 7 pins

Name
I/O
SDIO [0]
IO
SDIO [1] / TCON [4] /
BBLU [0]
SDIO [2] / TCON [3] /
BBLU [1]
SDIO [3] / PWM2 /
TCON [2]
SCLK
SCSB
RESET
Pin No
54
IO
53
IO
52
IO
51
Description
Serial control I/F data in/Parallel port data
[0]
Parallel port data [1] / TCON [4] / TTL
BBLU [0]
Parallel port data [1] / TCON [3] / TTL
BBLU [1]
Parallel port data [1] / TCON [4] / PWM2
I
I
O
50
111
56
Serial control I/F clock

Serial control I/F chip select
RESET output for Micron
Display & TCON/VIDEO -8 Port: 54 pins

:LVDS+RSDS+TTLO
:RSDS+TTLO
:RSDS+TTLIO
Pin
6-bits Dual 6-bits Single
8/6 bits
8 bits
NO
RSDS
RSDS
Dual/Single Dual/Single
LVDS
TTL
51
S [3] /
S 3] /
S [3] /
S [3] /
TCON [2] /
TCON [2] /
TCON [2] /
TCON [2] /
PWM2
PWM2
PWM2
PWM2
52
S [2] /
S [2] /
S [2] /
S [2] /
TCON [3]
TCON [3]
TCON [3]
BBLU [1] /
TCON [3]
53
S [1] /
S [1] /
S [1] /
S [1] /
TCON [4]
TCON [4]
TCON [4]
BBLU [0] /
TCON [4]
55
PWM2 /
PWM2 /
PWM2 /
PWM2 /
COUT /
COUT /
COUT /
COUT /
TCON [13]
TCON [13]
TCON [13]
TCON [13]
59
BB3P
BB3P
NC
BBLU [7]
60
BB3N
BB3N
NC
BBLU [6]
61
BB2P
BB2P
NC
BBLU [5]
62
BB2N
BB2N
NC
BBLU [4]
63
BB1P
BB1P
NC
BBLU [3]
/T0
64
BB1N
BB1N
NC
BBLU [2]
/T1
65
BCLKP
BCLKP
NC
BGRN [1] /
T2
66
BCLKN
BCLKN
NC
BGRN [0] /
T3
67
BG3P
BG3P
NC
BGRN [7]
68
BG3N
BG3N
NC
BGRN [6]
BGRN [5] /
73
BG2P
BG2P
TODP
T4
BGRN [4] /
74
BG2N
BG2N
TODN
T5
BGRN [3] /
75
BG1P
BG1P
TOCLKP
T6
BGRN [2] /
76
BG1N
BG1N
TOCLKN
T7
BRED [7] /
77
BR3P
BR3P
TOCP
T8
BRED [6] /
78
BR3N
BR3N
TOCN
T9
BRED [5] /
79
BR2P
BR2P
TOBP
T10
Note
(2), (3), / 2mA
(1), (2), (3), /
2mA
(1), (2), (3), /
2mA
(1), (2), (3), /
2mA
(2), (3), (5)
(2), (3), (5)
(2), (5), (6) / 2mA
:TTLO
:TTLIO
6 bits Dual 6 bits Single
TTL
TTL
Note
S [3] /
TCON [2] /
PWM2
S [2] /
TCON [3]
S [3] /
TCON [2] /
PWM2
S [2] /
TCON [3]
(1), (2), (3), /

2mA
S [1] /
TCON [4]
S [1] /
TCON [4]
(1), (2), (3), /

2mA
PWM2 /
COUT /
TCON [13]
BBLU [7]
BBLU [6]
BBLU [5]
BBLU [4]
BBLU [3]
PWM2 /
COUT /
TCON [13]
BBLU [7]
BBLU [6]
BBLU [5]
BBLU [4]
BBLU [3]
(1), (2), (3), /

2mA
BBLU [2]
BBLU [2]
TCON [6]
TCON [6]
TCON [5]
TCON [5]
BGRN [7]
BGRN [6]
BGRN [7]
BGRN [6]
BGRN [5]
BGRN [5]
BGRN [4]
BGRN [4]
BGRN [3]
BGRN [3]
BGRN [2]
BGRN [2]
BRED [7]
BRED [7]
BRED [6]
BRED [6]
BRED [5]
BRED [5]
(1), (2), (3), /

2mA
15
VE710s-4_VE710b-4
80
BR2N
BR2N
TOBP
81
BR1P
BR1P
TOAP
82
BR1N
BR1N
TOAP
85
AB3P
NC
TEDP
86
AB3N
NC
TEDN
87
AB2P
NC
TECLKP
88
AB2N
89
AB1P
90
BB1N
91
ACLKP
92
ACLKN
93
AG3P
94
99
100
101
102
AG3N
AG2P
NC
NC
NC
NC
NC
NC
NC
TCON [11]
TECLKN
TECP
TECN
TEBP
TEBN
TEAP
TEAN
NC
AG2N
TCON [10]
NC
AG1P
TCON [9]
NC
AG1N
TCON [8]
NC
TCON [7]
NC
TCON [6]
NC
TCON [5]
NC
TCON [1]
NC
TCON [0]
NC
BRED [4] /
T11
BRED [3] /
T12
BRED [2] /
T13
ABLU [7] /
T14
ABLU [6] /
T15
ABLU [5] /
T16
ABLU [4] /
T17
ABLU [3] /
T18
ABLU [2] /
T19
ABLU [1] /
T20
ABLU [0] /
T21
AGRN [7] /
T22
AGRN [6] /
T23
AGRN [5] /
T24
AGRN [4] /
T25
AGRN [3] /
T26
AGRN [2] /
T27
ARED [7] /
T28
ARED [6] /
T29
ARED [5] /
TH
ARED [4] /
TV
ARED [3] /
TE
ARED [2] /
TK
ARED [1]
BRED [4]
BRED [4]
BRED [3]
BRED [3]
BRED [2]
BRED [2]
ABLU [7]
ABLU [7]
ABLU [6]
ABLU [6]
ABLU [5]
ABLU [5]
ABLU [4]
ABLU [4]
ABLU [3]
ABLU [3]
ABLU [2]
ABLU [2]
TCON [1]
TCON [1]
TCON [0]
TCON [0]
AGRN [7]
AGRN [7]
AGRN [6]
AGRN [6]
AGRN [5]
AGRN [5]
AGRN [4]
AGRN [4]
AGRN [3]
AGRN [3]
AGRN [2]
AGRN [2]
ARED [7]
ARED [7]
ARED [6]
ARED [6]
ARED [5]
ARED [5]
ARED [4]
ARED [4]
ARED [3]
ARED [3]
ARED [2]
ARED [2]
COUT
ARED [0]
PWM2 /
COUT /
TCON [12]
TCON [11]
(1), (7), (8)
103
AR3P
104
AR3N
105
AR2P
106
AR2N
107
AR1P
108
AR1N
NC
113
PWM2 /
COUT /
TCON [12]
TCON [11]
/V [0]
TCON [10]
/V [1]
TCON [9] /
V [2]
TCON [8] /
V [3]
TCON [7] /
V [4]
PWM2 /
COUT /
TCON [12]
V [0]
PWM2 /
COUT /
TCON [12]
V [0]
V [1]
V [1]
BRED [1]
TCON [10]
(1), (7), (8)
V [2]
V [2]
BRED [0]
TCON [9]
(1), (7), (8)
V [3]
V [3]
AGRN [1]
TCON [8]
(1), (7), (8)
V [4]
V [4]
AGRN [0]
TCON [7]
(1), (7), (8)
114
115
116
117
118
NC
(9)
16
VE710s-4_VE710b-4
119
122
123
124
TCON [6] /
V [5]
TCON [5] /
V [6]
TCON [1] /
V [7]
TCON [0] /
VCLK
V [5]
V [5]
DHS
DHS
DHS
(1), (7), (8)
V [6]
V [6]
DVS
DVS
DVS
(1), (7), (8)
V [7]
V [7]
DENA
DENA
DENA
(1), (7), (8)
VCLK
VCLK
DCLK
DCLK
DCLK
(1), (7), (8)
*Single RSDS, even/odd swap, data (59~82) output to pin85~108, TCON (99~108) output to pin59~68.
*In 6-bit dual TTL output mode, Video8 cannot output TCON7~TCON11; while video8 can output TCON in
6-bit single TTL mode.
TMDS: 18 pins
Name
TMDS_TST/ PWM1
TMDS_GND
TMDS_VDD
NC
TMDS_VDD
NC
NC
TMDS_GND
NC
NC
TMDS_VDD
NC
NC
TMDS_GND
NC
NC
TMDS_GND
TMDS_VDD
I/O
AIO
Pin No
9
G
P
A
P
I
I
G
I
I
P
I
I
G
I
I
G
P
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Description
TMDS_TEST Pin / PWM1 / Power-on-latch
for serial / parallel port
(3.3V)
Impedance Match Reference.
(3.3V)
Differential Data Input
(3.3V)
(3.3V)
PWM Interface: (PWM1, PWM2 can be selected from 1 of 3 possible pins.)

Name
I/O
Pin No
Description
PWM2 / TCON [2] / S
O
51
PWM2 / TCON [2] / SDIO [3]
[3]
PWM2 / TCON [13] /
O
55
PWM2 / TCON [13] / Crystal out
COUT
PWM2 / TCON [12] /
O
113
PWM2 / TCON [12] / Crystal out
COUT
PWM1 / TMDS_TST
AIO
PWM1 / DDCSDA /
TCON [1] / BBLU [0]
PWM1 / TCON [7]
IO
47
IO
125
PWM0 / REFCLK
IO
112
Note
Note
(1), (2), (3), (5),
(8),
(2), (8), (9)
PWM1/ TMDS_TEST Pin/ Power-on-latch

for serial / parallel port
PWM1 / DDC serial control I/F data input /
output / TCON [4]
PWM1 / TCON [7]
PWM0 / (In / out) test pin for DCLK /
Video8 even-odd signal
(2), (8), (9) 6bit

dual TTL cannot
support
(2), (7), (8)
(1), (2), (3), (5),
(8),
(1), (2), (3), (5),
(8),
(2), (9)
17
VE710s-4_VE710b-4
DDC Channel:4 pins

Name
DDCSCL/TCON [0] /
BBLU [1]
DDCSDA/TCON [1] /
PWM1/BBLU [0]
TCON [5]
TCON [7]/PWM1
I/O
I
Pin No
46
IO
47
I
IO
126
125
Description
DDC serial control I/F clock/TCON [0]/TTL
BBLU [1]
DDC serial control I/F data input/ output/
TCON [1]/ PWM1/ TTL BBLU [0]
TCON [5]
TCON [7]/ PWM1
Power & Ground:22 pins

Name
I/O
Pin No
3.3V Power
P
49,121
3.3V Ground
G
48,120
3.3V Power
P
58,71,83, 95,110
3.3V Ground
G
57,72,84,96,109
2.5V Power
P
45,69,98,127
2.5V Ground
G
44,70,97,128
Note: (1) TTL compatible CMOS Input (Vt=1.7V); VCC=3.3V;
(2) 5V tolerance pad;
(3) Internal 75K Ohms pull high resistor.
(4) Internal 75K Ohms pull low resistor.
(5) Schmitt trigger CMOS Input (Vt=1.4~2.2V);
(6) Open-Drain, Output Drive low & Pull-high.
(7) Bi-directional input/output
(8) Programmable driving current (2~10mA)
(9) TTL output 5V & 3.3V
(10) 4V tolerance pad
Note
(2), (3), (5)
(1), (2), (3), (5),
(6), (8)/8mA/no
slew
(2), (3), (5)
(1), (2), (3), (5),
(6), (8)/8mA /no
slew
Description
VCCIO: 2
GNDIO: 2
PVCC: 5
PGND: 5
VCCK: 4
GNDK: 4
B. MTV312M64
The MTV312M micro-controller is an 8051 CPU core embedded device especially tailored for CRT/LCD
Monitor applications. It includes an 8051 CPU core, 1024-byte SRAM, 14 built-in PWM DACs, VESA DDC interface, 4-channel A/D
converter, and a 64K-byte internal program Flash -ROM.
A CMOS output pin means it can sink and drive at least 4mA current. It is not recommended to use such
pin as input function.
A open drain pin means it can sink at least 4mA current but only drive 10~20uA to VDD. It can be used as input or output function and needs
an external pull up resistor.
A 8051 standard pin is a pseudo open drain pin. It can sink at least 4mA current when output is at low level, and drives at least 4mA current
for 160nS when output transits from low to high, then keeps driving at 100uA to maintain the pin at high level. It can be used as input or output
function. It needs an external pull up resistor when driving heavy load device.
POWER CONFIGURATION
The MTV312M can work on 5V or 3.3V power supply system.
In 5V power system, the VDD pin is connected t o 5V power and the VDD3 needs an external capacitor, all
output pins can swing from 0~5V, input pins can accept 0~5V input range.
And ADC conversion range is 5V. However, X1 and X2 pins must be kept below 3.3V.
In 3.3V power system, the VDD and VDD3 are connected to 3.3V power, all output pins swing from 0~3.3V, HSYNC, VSYNC and open drain
pin can accept 0~5V input range, other pins must be kept below 3.3V. And the ADC conversion range is 3.3V.
C. INVERTER
In order to drive the CCFLs embedded in the panel module, there is a half bridge inverter to convert by the controller.
The input 12V up to hundreds of AC voltage output.
The inverter is formed by symmetric in order to drive the separate lamp modules.
The input stage consists of a PWM controller, half bridge inverter, and switching MOSFET to convert DC input into AC output.
The output stage consists of a tuning capacitor, coupling capacitor, transformer, push-pull MOSFET pair to boost AC output up to hundreds of
voltage.
And one resister is serial to lamp for output voltage feedback.
There are two signal to control the inverter which come from system.
Logic high level which send to I901 is turn on the inverter.
BRI signal control brightness by DC level which was integral from PWM signal.
18
VE710s-4_VE710b-4
5. Adjusting Procedure (VE710s-4/VE710b-4)

5.1.
5.2.
5.3.
ADJUSTMENT CONDITIONS AND PRECAUTIONS

1. Approximately 30 minutes should be allowed for warm up before proceeding.
2. Adjustments should be undertaken only on those necessary elements since most of them have been carefully
preset at the factory.
3. ESD protection is needed before adjustment.
MAIN ADJUSTMENTS
NO.
FUNCTION
1.
White Balance
2.
GEOMETRY
DESIGNATION
Function Key
Function Key
ALIGNMENT PROCEDURES
Adjustment Conditions and Precautions:
(A). Power supply voltage:
AC 110/120V10% 60 Hz5%, AC 220/240V10% 50 Hz 5%.
(B). Warm up time:
The display must be power ON for at least 30 minutes at full white pattern before starting alignments.
This is especially critical in color temperature and white balance adjustments.
(C). Signals: reference the front detail specifications and timing table.
Video : reference the front detail specifications.
1. Adjustment of White Balance:
A. TIMING: 1280x1024 64KHz/60Hz.
B. PATTERN: 5 Blocks.
C. LCD MONITOR set to 1280x1024 80K/75Hz BURN IN and warm up over 30 minutes.
D. CA110 color analizer at the center of screen and along a perpendicular to the screen at 20cm from the
display.
E. Power turn off, Press and 2 and turn on power at the same time after power LED is on,
release and 2 key, Then press 1 key go to factory mode. (Fig.1)
(Fig.1)
F.
Adjust Color Temperature:

(1) EEPROM INIT (5 BLOCKS):
Press key move cursor to EEPROM INIT, Press 2 key then monitor will INIT ADC value.
(2) Press key move cursor to White Balance, Press 2 key do white balance adjustment.
(3) Press key move cursor to Color Temerature Adjust, Press 2 key, Then OSD will display
Fig.2
19
VE710s-4_VE710b-4
(Fig.2)
(4) 9300K verify: move cursor to 9300K Press 2 key.
Press , key adjust R.G.B value
x=0.283 0.02
y=0.298 0.02
Press 1 key return to Fig.2
(5) 6500K verify: Repeat (4) press , move cursor to 6500K press
x=0.313 0.02
y=0.329 0.02
Y 240 cd/m2
2 key
(6) 5400K verify: Repeat (4) press , move cursor to 5400K press
x=0.332 0.02
y=0.348 0.02
2key
(7) Press 1 key go back to Fig.2, Then press

OFF/ON quit factory mode.
G.
1 key return to Fig.1, Power key
Color Temperature & Luminance Verify:

BRIGHTNESS MAX, CONTRAST MAX
9300K: x=0.283 0.02 y=0.298 0.02
6500K: x=0.313 0.02 y=0.329 0.02 Y240 cd/(CPT Panel) Y230 cd/(CMO Panel)
5400K: x=0.332 0.02 y=0.348 0.02
2. Geometry:
(a). Set cross-hatch pattern and preset timing as timing table listed.
(b). Change to each mode in turn and wait for the monitor finish auto-alignment and save process before
change to next mode.
(c). Until all of modes are agjusted, exit OSD menu and press PWR OFF to exit factory mode.
20
VE710s-4_VE710b-4
Firmware update procedure : (VE710s-4/VE710b-4)

When you received a received monitor , please check whether the firmware version. If not , please
followning procedures to upgrade to the latest version .
1. Equipment needed :
VA721/VE710s-4/VE710b-4
PC ( Personal computer )
LPT cable
Fixture (LM5ISP)
Firmware upgrade program
21
VE710s-4_VE710b-4
2. Connection :
To Monitor
To PC
Appendix A : How to install the software for ISP :

1. To setup ISP Environment :
Hardware: PC or notebook, parallel(printer) cable, ISP tooling.
Software: If OS was win2000 or WinXP , please install "PORT95NT.exe"
In order to ensure can execute ISP program, please set BIOS in PC or Notebook as Fig 0.0
Fig 0.0
22
VE710s-4_VE710b-4
2. Double-click the " PORT95NT.exe" in Windows & initall the program. , see Fig 0.1
Fig 0.1
3. Keep on press " Next " 4 times to go through the installation processes, see Fig. 0.2
Fig. 0.2
23
VE710s-4_VE710b-4
4. Choose " Typical " then press " Next " , see Fig. 0.3
Fig. 0.3
5. Keep on press " Next " 4 times to go through the installation processes, see Fig. 0.4
Fig. 0.4
24
VE710s-4_VE710b-4
6.Install completed , restart the PC or notebook. See Fig 0.5
Fig. 0.5
Install ISP
1. User could download ISP driver and PORT95NT install from Myson Century website (www.myson.com.tw )
2. After extracting the ZIP file , the total files list as Fig 1.0 , and double click the file of setup.exe to install.
Fig 1.0
25
VE710s-4_VE710b-4
3. Press " Next " button to continue., see Fig 1.1
Fig 1.1
4. Keep default setting or press " Change " button for selecting the path that you want , and then press " Next " button to
continue , see Fig 1.2
Fig 1.2
26
VE710s-4_VE710b-4
5. Press " Install " button to continue , see Fig 1.3
Fig. 1.3
6. Installation has finished , press " Finish " button , see Fig 1.4
Fig. 1.4
27
VE710s-4_VE710b-4
Appendix B : How to use software to upgrade the BIOS :

1. After installation , we could find the shortcut in the setting paah or the program bar ( default setting ) , see Fig 2.1
Fig. 2.1
2. Security file is a key to use ISP function , press " OK " button , see Fig 2.2
Fig. 2.2
3. The warning is used to remind user of that different CPU rate may cause ISP function fail.
(it's limited by IIC protocol ) , Press " OK " button , see Fig 2.3
Fig. 2.3
28
VE710s-4_VE710b-4
4. Press " Create Security file " button to key in Security code . Adjusting bar to decrease speed of IIC bus ,
See Fig.2.4 .
Speed of
IIC bus
Security code
Fig. 2.4
29
VE710s-4_VE710b-4
5. Fig 2.5 shows the setting for security code of software ISP . it needs 2 command No. and key in command sequentially
for 7C , 4C , 77. The command No. and command must be set by user while coding. About the detailed of setting , please
refer to section 6 boot code of ISP .
Fig. 2.5
30
VE710s-4_VE710b-4
Appendix C : Use ISP to program MCU

1.
Select MTV type first , load the binary or intel hex file that you want to program into the MCU ,
and select " AUTO" item , then press " RUN " button , see fig3.1
Step 2
Step 1
Step 3
Step 4
Fig. 3.1
31
VE710s-4_VE710b-4
2. If user change the MTV type , it must load file again , or the buffer of load file will be cleared .
3. CRC ( cyclic redundancy check ) : the host can check CRC register's result instead of reading every byte in flash .
The message of Check MCU CRC OK means that the host verify OK for the progress of program , see Fig.3.2
Fig. 3.2
32
VE710s-4_VE710b-4
Procedure of Disassembly (VE710s-4/VE710b-4/VA721)
This section provides disassembly procedures for VE710s-4/VE710b-4/VA721 LCD Monitor. Before
you begin any of these procedures, be sure to turn off the power, computer system, and other attached
devices; then disconnect the power cable from the electronically outlet. Moreover, when you
disassemble the monitor, be sure to put the screws in a safe place and separate them according to
grouping.
Disassembly of Stand unit from Monitor
Hinge Cover
Hinge Cover
!
"
X4
2080004800
1. Remove two Hinge Cover.

2. Unscrew four screws that secure Stand unit.
33
VE710s-4_VE710b-4
Stand unit
#
3. Detach Stand unit from the monitor.
34
VE710s-4_VE710b-4
Disassembly of Front Cover and Rear Cover
Front Cover
!
X2
2084730062
"
X2
2083740082
1.
2.
3.
Detach Front Cover from the monitor.

Unscrew two screws that secure Hinge Metal Fitting.
Unscrew two screws that secure Keypad Board.
Rear Cover
$
4.
Detach Rear Cover from the LCD Panel module.
35
VE710s-4_VE710b-4
Disassembly of LCD Panel
"
X1
2082630062
X1
2082630062
X1
2082630062
1.
2.
3.
Unscrew one screw that secure M/B Shielding Plate and detach M/B Shielding Plate.
Unscrew one screw that secure Inverter top Shielding Plate and detach Inverter top Shielding
Plate.
Unscrew one screw that secure Inverter down Shielding Plate and detach Inverter down Shielding
Plate.
4.
Disconnect three connectors to remove Inverter connector and LCD Panel FFC cable.
36
VE710s-4_VE710b-4
LCD Panel
%
X4
2080002200
5.
Unscrew four screws that secure Metal Fitting and remove LCD Panel from Metal Fitting.
37
VE710s-4_VE710b-4
Disassembly of Main Board, Keypad Board and Power Board
!
X4
2082730058
1. Unscrew four screws that secure Main Board and disconnect the wires which are connected to
Main Board and remove Main Board.
"
X4
2081430062
2. Unscrew four screws that secure Power Board to remove Power Board.
38
VE710s-4_VE710b-4
6. TROUBLE SHOOTING FLOW CHART

(VE710s-4 /VE710b-4 M -star Scaler)
6.1.
NO POWER
Check
3.3V O/P
C825
POWER
STAR
Check
P802 5,6 PIN
12V
PANEL
Check
Check
12V O/P
C823
Check F801
D801~D804
Check
P901,902,903,904
(EA03/03Q Panel
P901,902 Only)
I901,T901,T902,Q904,
Q905,Q910,Q911
(EA03/03Q Panel Q910,Q911
Differ L901,L902)
Check
D822
I802,I803
Check
I801
,Q801
3.3V
Check
I901
12V
MAIN PCB
STAR
CHECK
MAIN PCB
N
5V OK?
CHECK
POWER PCB
OK?
Y
N
3.3V OK?
CHECK
I103,
SUROUND CAP
BEAD OK?
CHECK
I106,I107
SUROUND CAP
OK?
CHECK
I104,
SUROUND CAP
BEAD OK?
CHECK
I101,
SUROUND CAP
BEAD OK?
Y
N
1.8V OK?
39
VE710s-4_VE710b-4
6.2.
NO DISPLAY
No
Display
Check Power
region
Dark
Amber
Check LED Color
Check IO cable is
connect OK ?
Yes
Amber & Green
No
Check X102 Crystal

12MHz is working?
Green
Check I/P signal is in

pwr saving state?
Check I106 is OK ?
Yes
Refer to NO POWER
trouble shoot flow char
Press Power key

ON/OFF is OK ?
(See LED is green or
dark.)
No
Yes
Check uP I106
Reset is Ok ?
No
Yes
Press "1" key if OSD

menu is on display ?
No
Change
I106
Check Reset circuit

C173,D125
Check Keypad
pcb is OK ?
Yes
Check if
Inverter is Ok ?
Yes
Check I105
MST8016A if
HWRST Pin#32 have
reset pulse ?
No
Change
Inverter
Check uP I106
pin#17 send reset
pulse ?
No
Yes
Yes
Check X101 Crystal
14.318MHz is
working ?
No
Change X101
Yes
Check I105
Pin#70,71 data bus
have signal
No
Change I105 LCD

controller IC
Yes
Check panel Powers
VLCD_3V3
VLCD_12V
correct
Yes
Change LCD panel
40
VE710s-4_VE710b-4
(VE710s-4 /VE710b-4 Realtek Scaler)
6.1.
NO POWER
Check
3.3V O/P
C825
POWER
STAR
Check
P802 5,6 PIN
12V
PANEL
Check
Check
12V O/P
C823
Check F801
D801~D804
Check
P901,902,903,904
(EA03/03Q Panel
P901,902 Only)
I901,T901,T902,Q904,
Q905,Q910,Q911
(EA03/03Q Panel Q910,Q911
Differ L901,L902)
Check
D822
I802,I803
Check
I801
,Q801
3.3V
Check
I901
12V
MAIN PCB
STAR
CHECK
MAIN PCB
N
3.3V OK?
Y
2.5V OK?
CHECK
POWER PCB
OK?
Y
CHECK
I107
SUROUND CAP
BEAD OK?
CHECK
I101,I104
SUROUND CAP
OK?
CHECK
I106
SUROUND CAP
BEAD OK?
CHECK
I101
SUROUND CAP
BEAD OK?
41
VE710s-4_VE710b-4
6.2.
NO DISPLAY
No
Display
Check Power
region
Dark
Amber
Check LED Color
Check IO cable is
connect OK ?
Yes
Amber & Green
No
Check X101 Crystal

12MHz is working?
Green
Check I/P signal is in

pwr saving state?
Check I104 is OK ?
Yes
Refer to NO POWER
trouble shoot flow char
Press Power key

ON/OFF is OK ?
(See LED is green or
dark.)
No
Yes
Check uP I104
Reset is Ok ?
No
Yes
Press "1" key if OSD

menu is on display ?
No
Change
I106
Check Reset circuit

C117,Q101
Check Keypad
pcb is OK ?
Yes
Check if
Inverter is Ok ?
Yes
Check X102 Crystal
14.318MHz(CPT Panel)
24.576MHz(CMO Panel)
is working ?
No
Check
Inverter
Circuit
No
Change X102
Yes
Check I101
Pin#73,74 data bus
have signal
No
Change I101 LCD

controller IC
Yes
Check panel Powers
VLCD_3V3(CPT Panel)
VLCD_5V(CMO Panel)
correct
Yes
Change LCD panel
42
VE710s-4_VE710b-4
7. Recommended Spare Parts List

RECOMMENDED SPARE PARTS LIST (VE710s-4 for "CPT v1.1 (8ms) Panel")
ViewSonic Model Number: VS10047
Rev: 1b
Serial No. Prefix: PUP
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Board Assembly:
Cabinets:
Cables:
Documentation:
Electronic
Components:
Packing Material:
Plastics:
Description
PCB ASS'Y BLOCK (MAIN)
PCB ASS'Y BLOCK (POWER)
PCB ASS'Y BLOCK (CON)
DUST COVERVE710 ABS94HB AL-PLATE(L)
DUST COVERVE710 ABS94HB AL-PLATE(L) ROHS
DUST COVERVE710 ABS94HB AL-PLATE(R) R
DUST COVERVE710 ABS94HB AL-PLATE(R) ROHS
CABI BACKVE710 ABS94HB BLACK 4001
CABI BACKVE710 ABS94HB BLACK 4001 ROHS
FRONTBEZEL VIEWSONIC VE710 ABS94HB PS7604B
FRONT BEZELVE710 ABS94HB PS7604B
I/O Cable D15/C13 20276(4.5) 1.83M Black
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
GUARANT CARD VIEWSONIC VA721/VE910 QSG
GUARANT CARD VIEWSONIC VA721/VE910 QSG ROHS
CD-OWNER GUIDE VE710S-4 WIZARD VS10047 CPT
CD-OWNER GUIDE VE710S-4 WIZARD VS10047 CPT ROHS
LCD PANEL CLAA170EA08Q Ver1.1 8ms CPT
LCD PANEL CLAA170EA08Q Ver1.1 8ms CPT ROHS
CAPACITOR - X2 0.47u/275V P=15.0 KC
POLYETHY BAG 250mmx350mmxt0.3 ADD>PE-LD<
POLYETHY BAG 90CMX75CMX0.02t PE-LD
Name Plate (ViewSonic Logo 3 Pin VA521)
CARTON BOX VE710S-4 VS10047 050530
POLYFOAM VE710 EPS (L)
POLYFOAM VE710 EPS (L) ROHS
POLYFOAM VE710 EPS (R)
POLYFOAM VE710 EPS (R) ROHS
STAND VE710 ABS94HB BLACK 4001
STAND VE710 ABS94HB BLACK 4001 ROHS
ECR/ECN
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 6/9/06
Added on 6/20/06
Added on 06/20/06
Added on 06/20/06
Added on 6/9/06
Added on 6/9/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
ViewSonic P/N
B-00003459
B-00003460
B-CB-0206-0186
C-00003453
C-00006124
M-CV-0830-0300
C-00006123
C-BC-0302-0587
C-00006126
C-FP-0301-0980
C-00006196
CB-00003009
A-VIO-0118-0034
DC-00003455
DC-00004478
DC-00003475
DC-00006127
E-00003468
E-00006128
E-00005729
M-MS-0808-1316
M-MS-0808-1317
M-MS-0808-9213
P-00006129
P-FM-0602-0866
P-00006130
P-FM-0602-0867
P-00006131
PL-PS-0715-0990
PL-00006125
Ref. P/N
6201-7978908191
6204-7978908191
6202-7978908251
2027258602
2027258602P
2027258601
2027258601P
2022262301
2022262301P
2603307568
2024266901P
2427501191P
2427501174P
2002310496
2002310496P
2438501209
2438501209P
2212007201
2212007201P
2300947481P
2013222536P
2013053000P
2051352001P
2011132010P
2012176400
2012176400P
2012176500
2012176500P
2028258201
2028258201P
Location
Universal number#
6B04
6B04
6B02
6B02
2C01
2C01
1F01
P961
P961
6P84
6P84
6P80
6P80
V901
V901
C801
6P85
6P60
1F04
6P01
6P20
6P20
6P21
6P21
5B01
5B01
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
M-Region (VE710s-4M)
Item
1
Accessories:
Description
POWER CORD USA WALL 1.83M BLACK
ECR/ECN
ViewSonic P/N
A-PC-0106-0121
Ref. P/N
2427130046P
Location
P951
Universal number#
Q'ty
1
Description
AC POWER CORD TAIWAN WALL 1.83M BLACK
ECR/ECN
ViewSonic P/N
A-00003458
Ref. P/N
2427130123A
Location
P951
Universal number#
Q'ty
1
Description
POWER CORD CHINA WALL 1.83M BLACK
POWER CORD CHINA WALL 1.83M BLACK ROHS
DISPLAY CARD VIEWSONIC CRT QUALIFIED LABEL
GUARANT CARD VIEWSONIC WARRANTY CARD-C 2004
ECR/ECN
ViewSonic P/N
A-PC-0106-0277
A-00006132
B-00003459
B-00003460
M-LB-0813-0984
DC-00003461
Ref. P/N
2427130097
2427130097P
6201-7978908191
6204-7978908191
2002201323P
2002310402P
Location
P951
P951
Universal number#
Q'ty
1
1
1
1
1
1
ViewSonic P/N
A-00006133
A-PC-0106-0138
CB-00006136
CB-00006137
P-00006134
Ref. P/N
2427130047P
2427130047
2420308001P
2420308002P
2011132012P
Universal number#
Q'ty
P-Region (VE710s-4P)
Item
1
Accessories:
G-Region (VE710s-4G)
Item
1
2
3
4
5
6
Accessories:
Board Assembly:
Documentation:
Added on 06/20/06
6P09
6P07
E-Region (VE710s-4E)
Item
1
2
4
5
6
Accessories:
Cables:
Packing Material:
Description
POWER CORD GERMAN WALL 1.83M BLACK ROHS
POWER CORD GERMAN WALL 1.83M BLACK
FFC CABLE 50P*0.5*L80mm
FFC CABLE 30P*0.5*L80mm
CRAFT BOX VE710S-4 VS10047 ROHS MARK
ECR/ECN
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Location
P951
P981
P980
6P01
1
1
1
Remark 1: Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation.
This is to eliminate repeated cross checks of each item between this version and prior versions.
43
VE710s-4_VE710b-4
RECOMMENDED SPARE PARTS LIST (VE710s-4 for "CMO v2.1 (8ms) Panel")
Rev: 1b
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Board Assembly:
Cabinets:
Cables:
Documentation:
Electronic
Components:
Packing Material:
Plastics:
Description
BEZEL ASS'Y VE710 ABS94HB PS7604B
CABI BACK ASSY VE710 ABS94HB BLACK 4001
CABI BACKVE710 ABS94HB BLACK 4001 ROHS
DUST COVER VE710 ABS94HB AL-PLATE(L)
DUST COVERVE710 ABS94HB AL-PLATE(L) ROHS
DUST COVER VE710 ABS94HB AL-PLATE(R) R
DUST COVERVE710 ABS94HB AL-PLATE(R) ROHS
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
CD-OWNER GUIDE VE710S-4 WIZARD VS10047 CMO
CD-OWNER GUIDE WIZARD VS10047 CMO ROHS
GUARANT CARD VIEWSONIC VA721/VE910 QSG ROHS
LCD PANEL M170E5-L09 Ver2.1 CMO
STAND VE710 ABS94HB BLACK 4001 ROHS
ECR/ECN
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 6/9/06
Added on 06/20/06
Added on 6/20/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
ViewSonic P/N
B-CB-0206-0186
B-00003450
B-00003451
C-FP-0301-0979
C-BC-0302-0587
C-00006126
C-00003453
C-00006124
M-CV-0830-0300
C-00006123
A-VIO-0118-0034
CB-00003009
DC-00003454
DC-00006140
DC-00003455
DC-00004478
E-00003456
E-00006139
P-00003476
M-MS-0808-1316
M-MS-0808-1317
P-FM-0602-0866
P-00006130
P-FM-0602-0867
P-00006131
PL-PS-0715-0990
PL-00006125
Ref. P/N
6202-7978908251
6201-7978908141
6204-7978908141
2024266901
2022262301
2022262301P
2027258602
2027258602P
2027258601
2027258601P
2427501174
2427501191P
2438501199
2438501199P
2002310496
2002310496P
2212008000
2212008000P
2011132010
2013222536
2013053000
2012176400
2012176400P
2012176500
2012176500P
2028258201
2028258201P
Location
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6B02
6B04
2C01
6B04
6B04
6B02
6B02
P961
P961
6P80
6P80
6P84
6P84
V901
V901
6P01
6P85
6P60
6P20
6P20
6P21
6P21
5B01
5B01
M-Model
Item
1
Accessories:
Description
ECR/ECN
ViewSonic P/N
A-PC-0106-0121
Ref. P/N
2427130046
Location
P951
Universal number#
Q'ty
1
Description
ECR/ECN
ViewSonic P/N
A-00003458
Ref. P/N
2427130123A
Location
P951
Universal number#
Q'ty
1
ECR/ECN
ViewSonic P/N
A-PC-0106-0277
A-00006132
B-00003459
B-00003460
M-LB-0813-0984
DC-00003461
Ref. P/N
2427130097
2427130097P
6201-7978908191
6204-7978908191
2002201323
2002310402
Location
P951
Universal number#
Q'ty
1
ViewSonic P/N
A-PC-0106-0138
CB-00006138
PL-00006135
P-00006134
Ref. P/N
2427130047
2420316301P
2603207018
2011132012P
P-Model
Item
1
Accessories:
G-Model
Item
1
2
3
4
5
6
Accessories:
Board Assembly:
Documentation:
Description
Added on 06/20/06
1
1
1
1
6P09
6P07
E-Model
Item
1
2
3
4
Accessories:
Cable:
Plastics:
Packing Material:
Description
FFC CABLE 30P*1.0mm*L165mm
Stand Assy VE710 ABS94HB BLACK 4001
CRAFT BOX VE710S-4 VS10047 ROHS MARK
ECR/ECN
Added on 06/20/06
Added on 06/20/06
Added on 06/20/06
Location
P951
P980
Universal number#
6P01
Q'ty
1
1
1
44
VE710s-4_VE710b-4
ViewSonic Confidential
Creation Date: 07/19/05
RECOMMENDED SPARE PARTS LIST (VE710b-4 for "CPT v1.1 (8ms) Panel")
Rev: 1b
Serial No. Prefix: PUN
Item
ViewSonic P/N
Ref. P/N
B-CB-0206-0186
6202-7978908251
B-00003450
6201-7978908141
B-00003451
6204-7978908141
C-FP-0301-0978
2603307569
6B02
1
1
Description
Board Assembly:
Cabinets:
ECR/ECN
BEZEL ASS'Y VE710B-2 ABS94HB PANTONE 432C
Location
Universal number#
Q'ty
CABI BACK ASSY VE710B-2 ABS94HB PANTONE 432C
C-00003452
2603407603
6B04
C-00003453
2027258602
6B04
DUST COVER (VE710 ABS94HB AL-PlATE (LD)
C-00006124
2027258602P
6B04
M-CV-0830-0300
2027258601
6B02
DUST COVER (VE710 ABS94HB AL-PLATE (R)
C-00006123
2027258601P
6B02
A-VIO-0118-0034
2427501174
P961
CB-00003009
2427501191P
P961
DC-00003467
2438501210
6P80
DC-00006200
2438501210P
6P80
DC-00003455
2002310496
6P84
DC-00004478
2002310496P
6P84
E-00003468
2212007201
V901
Added on 06/23/06
E-00006128
2212007201P
V901
Added on 6/9/06
E-00006201
2300947481p
C801
P-00003457
2011132011
6P01
10
Cables:
ROHS
I/O Cable D15/C13 20276(4.5) 1.83M Black ROHS

Documentation:
CD-ROM VE710B-4 WIZARD VS10047 CPT ROHS
14
QUICK START GUIDE VA721/VE910
15
QUICK START GUIDE VA721/VE910 ROHS

Electronic
Components:
17

Packing Material:
Added on 6/9/06
Added on 06/23/06
Added on 06/23/06

LCD PANEL CLAA170EA-08Q V1.1 8MS CPT ROHS
18
19
Added on 06/23/06
CD-ROM VE710B-4 WIZARD VS10047 CPT
13
16
Added on 06/23/06
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
11
12
ROHS
CARTON BOX VE710B-4 VS10047 050530
20
M-MS-0808-1316
2013222536
6P85
21
M-MS-0808-1317
2013053000
6P60
22
M-MS-0808-9213
2051352001P
1F04
23
P-FM-0602-0866
2012176400
6P20
24
P-00006130
2012176400P
6P20
25
P-FM-0602-0867
2012176500
6P21
26
27

Plastics:
Added on 6/9/06
Added on 06/23/06
Added on 06/23/06
P-00006131
2012176500P
6P21
PL-PS-0715-0991
2028258202
5B01
Added on 06/23/06
PL-00006199
2028258202P
5B01
ECR/ECN
ViewSonic P/N
Ref. P/N
A-00005362
2427130046P
STAND VE710B-2 ABS94HB PANTONE 432C
28
STAND (VE710B-2 ABS94HB PANTONE 432C) ROHS
M-Model (VE710b-4M)
Item
1
Description
Accessories:
Location
Universal number#
P951
Q'ty
1
P-Model (VE710b-4P)
Description
Item
1
Accessories:
ECR/ECN
ViewSonic P/N
Ref. P/N
A-00003458
2427130123A
Location
Universal number#
P951
Q'ty
1
G-Model (VE710b-4G)
Description
Item
1
Accessories:
2
3
Board Assembly:
4
5
6
ViewSonic P/N
Ref. P/N
A-PC-0106-0277
2427130097
P951
A-00006132
2427130097P
P951
B-00003459
6201-7978908191
B-00003460
6204-7978908191
C-00006202
2022262302P

Cabinet:
Documentation:
7
8
ECR/ECN
Added on 06/23/06

Packing Material:
CARTON BOX VE710B-4 VS10047 ROHS MARK
Added on 06/23/06
Location
Universal number#
Q'ty
1
1
1
1
2C01
M-LB-0813-0984
2002201323
6P09
DC-00003461
2002310402
6P07
P-00006203
2011132013P
6P01
E-Model (VE710b-4E)
Description
Item
1
Accessories:
2
3
Cables:
4
5
Plastics:
ECR/ECN
ViewSonic P/N
Ref. P/N
A-PC-0106-0138
2427130047
Location
Universal number#
Q'ty
P951
Added on 06/23/06
A-00006133
2427130047P
P951
FFC 50P*0.5*L80mm
Added on 06/23/06
CB-00006136
2420308001P
P981
FFC 30P*0.5*L80mm
Added on 06/23/06
CB-00006137
2420308002P
P980
STAND ASSY VE710B-2 ABS94HB PANTONE 432C
Added on 06/23/06
PL-00006204
2603207019
1
1
45
VE710s-4_VE710b-4
ViewSonic Confidential
Creation Date: 07/19/05
RECOMMENDED SPARE PARTS LIST (VE710b-4 for "CMO v2.1 (8ms) Panel")
Rev: 1b
Item
ViewSonic P/N
Ref. P/N
B-CB-0206-0186
6202-7978908251
B-00003450
6201-7978908141
B-00003451
6204-7978908141
C-FP-0301-0978
2603307569
6B02
1
1
Description
Board Assembly:
Cabinets:
ECR/ECN
BEZEL ASS'Y VE710B-2 ABS94HB PANTONE 432C
Location
Universal number#
Q'ty
C-00003452
2603407603
6B04
C-00003453
2027258602
6B04
DUST COVER (VE710 ABS94HB AL-PlATE (LD)
C-00006124
2027258602P
6B04
DUST COVER (VE710 ABS94HB AL-PLATE (R)
10
Cables:

Documentation:
13
14
15
Added on 06/23/06
2027258601
6B02
C-00006123
2027258601P
6B02
A-VIO-0118-0034
2427501174
P961
CB-00003009
2427501191P
P961
DC-00003454
2438501198
6P80
DC-00003455
2002310496
6P84
DC-00004478
2002310496P
6P84
E-00003456
2212008000
V901
E-00006201
2300947481p
C801
P-00003457
2011132011
6P01
ROHS
Added on 06/23/06

Packing Material:
Added on 6/9/06
M-CV-0830-0300
CD-OWNER GUIDE VE710B-4 WIZARD VS10047 CMO
QUICK START GUIDE VA721/VE910

Electronic
Components:
16
17
ROHS
Added on 06/23/06
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
11
12
ROHS
Added on 6/9/06
18
M-MS-0808-1316
2013222536
6P85
19
M-MS-0808-1317
2013053000
6P60
20
M-MS-0808-9213
2051352001P
1F04
21
P-FM-0602-0866
2012176400
6P20
22
P-00006130
2012176400P
6P20
23
P-FM-0602-0867
2012176500
6P21
24
25

Plastics:
Added on 6/9/06
Added on 06/23/06
Added on 06/23/06
P-00006131
2012176500P
6P21
PL-PS-0715-0991
2028258202
5B01
Added on 06/23/06
PL-00006199
2028258202P
5B01
ECR/ECN
ViewSonic P/N
Ref. P/N
A-00005362
2427130046P
26
STAND (VE710B-2 ABS94HB PANTONE 432C) ROHS
M-Model (VE710b-4M)
Item
1
Description
Accessories:
Location
Universal number#
P951
Q'ty
1
P-Model (VE710b-4P)
Item
1
Description
Accessories:
ECR/ECN
ViewSonic P/N
Ref. P/N
A-00003458
2427130123A
Location
Universal number#
P951
Q'ty
1
G-Model (VE710b-4G)
Item
1
2
3
Board Assembly:
Documentation:
ECR/ECN
Ref. P/N
2427130097
P951
A-00006132
2427130097P
P951
B-00003459
6201-7978908191
B-00003460
6204-7978908191
M-LB-0813-0984
2002201323
6P09
DC-00003461
2002310402
6P07

AC POWER CORD CHINA WALL 1.83M BLACK ROHS
4
5
ViewSonic P/N
A-PC-0106-0277
Description
Accessories:
Added on 06/23/06

Location
Universal number#
Q'ty
1
1
E-Model (VE710b-4E)
Item
1
2
Description
Accessories:
ECR/ECN

Added on 06/23/06
ViewSonic P/N
Ref. P/N
A-PC-0106-0138
2427130047
P951
Location
Universal number#
Q'ty
1
A-00006133
2427130047P
P951
46
VE710s-4_VE710b-4
BOM LIST (VE710s-4)

ViewSonic Model Number: VS-10047
Rev: 1a
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
ViewSonic P/N
E-C-0404-3898
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-3898
N/A
N/A
N/A
N/A
E-C-0404-3898
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-3815
E-C-0404-4423
E-C-0404-4423
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-4423
E-C-0404-4423
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
E-D-0403-1779
E-D-0403-2808
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
E-D-0403-1779
E-D-0403-2808
E-D-0403-1779
E-D-0403-2808
N/A
E-D-0403-1892
E-00003830
Ref. P/N
2341110096P
2346147396P
2346247396P
2346147396P
2346247396P
2346147396P
2346247396P
2341110096P
2346147396P
2346247396P
2346147396P
2346247396P
2341110096P
2346147396P
2346247396P
2341147096P
2341147096P
2341147096P
2341147096P
2346410496P
2341122096P
2341122096P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2341122096P
2341122096P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364503996P
2364505616P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364503996P
2364505616P
2364503996P
2364505616P
2364600196P
2364200896P
2364601396P
Description
CAP,CHIP 125'C CS 0603/COG/50V 10 p J T
CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T
CAP,CHIP 125'C CS 0603/COG/50V 47p J T
CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T
DIODE,SWITCH SMD (NG PARTS) LL4148 SOD80C TEMIC
DIODE,RECT(SMD) BAS32L SOD80C PHILIPS
DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES
DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS
DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY
Location
C101
C102 RA
C102 RB
C103 RA
C103 RB
C104 RA
C104 RB
C105
C106 RA
C106 RB
C107 RA
C107 RB
C108
C109 RA
C109 RB
C111
C113
C114
C115
C116
C119
C121
C122
C133
C134
C135
C136
C137
C138
C139
C140
C141
C142
C143
C145
C146
C148
C149
C151
C154
C157
C158
C160
C161
C162
C163
C166
C167
C168
C169
C170
C172
C175
C178
C179
C180
D101 RA
D101 RB
D101 RC
D103 RA
D103 RB
D103 RC
D104 RA
D104 RB
D104 RC
D105 RA
D105 RB
D106 RA
D106 RB
D106 RC
D107 RA
D107 RB
D107 RC
D108 RA
D108 RB
D108 RC
D111 RA
D111 RB
D112 RA
D112 RB
D113 RA
D113 RB
D113 RC
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
47
VE710s-4_VE710b-4
Item
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
ViewSonic P/N
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
N/A
E-IC-0401-2269
N/A
N/A
N/A
E-R-0405-6600
E-R-0405-6600
E-R-0405-6600
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00003533
E-00003533
E-00003533
N/A
N/A
N/A
N/A
N/A
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
N/A
E-Q-0402-1624
E-Q-0402-1180
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
E-Q-0402-1624
E-Q-0402-1180
N/A
N/A
N/A
N/A
N/A
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6600
E-R-0405-6409
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6409
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6604
E-R-0405-6604
E-R-0405-6409
E-R-0405-6410
E-R-0405-6600
E-R-0405-6601
E-R-0405-6419
E-R-0405-6419
Ref. P/N
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2365930896P
2365929996P
2365915896P
2365100996P
2365812696P
2365813196P
2253200096P
2253200096P
2253200096P
2379312196P
2379312196P
2379820196P
2379820196P
2379820196P
2379820196P
2379820196P
2379520196P
2379520196P
2379520196P
2253300096P
2407630230P
2407630330P
2407630250P
2407630350P
2360100696P
2360100796P
2360100696P
2360100796P
2360100696P
2360100796P
2360501396P
2360501296P
2360301696P
2360301296P
2360100696P
2360100796P
2360100696P
2360100796P
2360301696P
2360301296P
2259210308P
2259210308P
2259210308P
2259210308P
2259222008P
2253200096P
2253210196P
2251275096P
2253200096P
2253210196P
2253200096P
2253210196P
2251275096P
2253210196P
2253200096P
2253210196P
2251275096P
2253210196P
2253210196P
2253222296P
2253222296P
2253210196P
2253210296P
2253200096P
2253210596P
2253247296P
2253247296P
Description
IC,DIGITAL SMD RTD2023-LF PQFP128 Realtek
IC,DIGITAL SMD MTV312GMV64 PLCC44 MYSON
IC,DIGITAL SMD 24LC16BT/SN SO-8 MICROCHIP
MEMORY IC AT24C16AN-10SU-2.7 SO-8 AMTEL
IC,LINEAR(SMD) CM2860GK1M223 SOT223 CHAMPION
IC,LINEAR(SMD) AME8805DEGTZ SOT-223 AME
RES CHIP 1/10W RC 0603 1/10W 0 ohm J T
BEAD,HI-IMPEDANCE Z= 120 ohm(100MHZ~) 0603 200mA
BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A
RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T
SOCKET,SMD 6240-30-OR5P 0.5*30P KYOCERA
SOCKET,SMD 2206BL11230RLP 0.5*30P FARNCON
SOCKET,SMD 6240-50-0R5P 0.5*50P KYOCERA
XISTOR,PNP R SMD PMBS3906 SOT-23 PHILIPS
XISTOR,PNP R SMD MMBT3906-F SOT-23 DIODES
FET,P-CH SMD AP2305GN SOT23 APEC
FET,P-CH SMD (EOL) AO3411 SOT-23 AOS
XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS
XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES
RES,CHIP NETWORKS 8P4R 1/16W 10Kohm J P=0.8
RES,CHIP NETWORKS 8P4R 1/16W 22 ohm J P=0.8
RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T
RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T
RES CHIP 1/10W RC 0603 1/10W 1.0Mohm J T
Location
D114 RA
D114 RB
D114 RC
D116 RA
D116 RB
D116 RC
D117 RA
D117 RB
D117 RC
D119 RA
D119 RB
D119 RC
D120 RA
D120 RB
D120 RC
D121 RA
D121 RB
D121 RC
D122 RA
D122 RB
D122 RC
I101
I104
I105 RA
I105 RB
I106 RA
I106 RB
L101
L102
L103
L104
L105
L106
L107
L108
L109
L110
L111
L112
L113
L115
P106 RA
P106 RB
P107 RA
P107 RB
Q101 RA
Q101 RB
Q102 RA
Q102 RB
Q103 RA
Q103 RB
Q104 RA
Q104 RB
Q106 RA
Q106 RB
Q107 RA
Q107 RB
Q108 RA
Q108 RB
Q109 RA
Q109 RB
RN1
RN2
RN3
RN4
RN5
R102
R103
R104
R105
R106
R107
R108
R109
R110
R111
R112
R113
R114
R116
R118
R119
R120
R124
R125
R127
R128
R129
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
48
VE710s-4_VE710b-4
Item
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
ViewSonic P/N
E-R-0405-6410
E-R-0405-6409
E-R-0405-6410
E-R-0405-6409
E-R-0405-6409
E-R-0405-6604
E-R-0405-6604
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6411
N/A
E-R-0405-6419
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6419
E-R-0405-6601
E-R-0405-6419
E-R-0405-6410
E-R-0405-6419
N/A
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6411
E-R-0405-6419
E-R-0405-7000
N/A
E-R-0405-6409
E-R-0405-6410
N/A
E-R-0405-6411
N/A
E-R-0405-6410
E-R-0405-6603
E-R-0405-6603
E-R-0405-6603
N/A
E-R-0405-6600
E-R-0405-6411
N/A
N/A
N/A
N/A
E-00000999
N/A
N/A
E-00000999
E-00000999
N/A
E-00000999
E-00000999
N/A
E-Q-0402-0839
N/A
M-MS-0808-6355
N/A
N/A
E-X-0415-0119
E-X-0415-0112
N/A
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
N/A
N/A
N/A
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
E-00003534
E-00003830
N/A
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
Ref. P/N
2253210296P
2253210196P
2253210296P
2253210196P
2253210196P
2253222296P
2253222296P
2251290916P
2253210196P
2253210196P
2253210396P
2251233216P
2253247296P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253247296P
2253210596P
2253247296P
2253210296P
2253247296P
2253300096P
2253300096P
2253210196P
2253210196P
2253210396P
2253247296P
2253222196P
2253347296P
2253210196P
2253210296P
2253300096P
2253210396P
2253227296P
2253210296P
2253222096P
2253222096P
2253222096P
2253347296P
2253200096P
2253210396P
2336310613P
2336322613P
2336322613P
2336322613P
2336347613P
2336310713P
2336322613P
2336347613P
2336347613P
2336322613P
2336347613P
2336347613P
2336322613P
2361111191P
2404301112P
2404301107P
2404371008P
2202518300P
2369103601P
2369103901P
2363703891P
2403702200P
2403702200P
2403702200P
2403702200P
2403702200P
2202127900P
2427408252P
2364530016P
2364600396P
2363600696P
2364601396P
2364600396P
2363600696P
2364601396P
2364600396P
2363600696P
2364601396P
2364300896P
2364600396P
2363600696P
2364601396P
2364600396P
Description
RES,CHIP 1/10 RC 0603 1/10W 9.09Kohm F T
RES CHIP 1/10W RC 0603 1/10W 10Kohm J T
RES CHIP 1/8W RC 0805 1/8 W 4.7Kohm J T
CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T
CAP,MINI ELE 105'C EC 100u/ 16V 6.3*7 P=2.5 T
XISTOR,PNP R 2SA1020(Y) TO-92 TOSHIBA
CONNECTOR JST PH 13P SIDE P=2.0 OR EQUAL
CONNECTOR JST PH 9P TOP P=2.0 OR EQUAL
PCB MULTILAYER VA521(A) M/B FR4*2 100*82 1.00
XTAL,OSC 12.0000MHZ/49US 0.1mW/30pF
LED 3 GRN/YEL
TACT SWITCH TSAA-2 HUAJIE
PC BOARD VA721 K/B FR1 120*21 V1.00
WIRE HARNESS 8/8P H/B 1061#26 L=250mm p=2.0
DIODE,ZENER SMD MMSZ5256B SOD-123 PEC
DIODE,SWITCH SMD LL4148 SOD-80 DIODES
DIODE,SWITCH RLS4148-T11 SOD-80 ROHM
DIODE,SCHOTTKY(SMD) EP05Q04-TE8L 40V/0.4A IR
Location
R130
R132
R133
R134
R135
R139
R140
R142
R144
R145
R146
R148
R149
R150
R151
R152
R153
R154
R155
R156
R157
R158
R159
R161
R163
R166
R170
R176
R177
R180
R181
R182
R183
R186
R188
R189
R190
R191
R192
R193
R194
R195
R196
R197
R199
C117
C132
C144
C147
C155
C156
C159
C164
C165
C171
C176
C177
C181
Q105
P101
P104
P105
U101
X101
X102
D701
S701
S702
S703
S704
S705
U701
P701
D808
D907 RA
D907 RB
D907 RC
D908 RA
D908 RB
D908 RC
D909 RA
D909 RB
D909 RC
D910
D911 RA
D911 RB
D911 RC
D912 RA
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
49
VE710s-4_VE710b-4
Item
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
ViewSonic P/N
E-00003534
E-00003830
N/A
N/A
E-00003850
E-00003851
E-Q-0402-1180
E-Q-0402-1377
E-Q-0402-1376
E-Q-0402-1608
E-Q-0402-1378
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00001013
E-00001013
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-4833
E-C-0404-2982
E-C-0404-1838
E-C-0404-3243
E-C-0404-1861
N/A
N/A
N/A
N/A
N/A
N/A
E-00003555
E-C-0404-1424
E-C-0404-4833
E-C-0404-1833
E-C-0404-1815
N/A
E-C-0404-2272
E-C-0404-2272
E-C-0404-1833
N/A
E-C-0404-0287
E-C-0404-3470
N/A
N/A
N/A
N/A
E-C-0404-4833
E-C-0404-4833
Ref. P/N
2363600696P
2364601396P
2360302296P
2360301096P
2360302396P
2360302496P
2360301296P
2360300396P
2360300296P
2360300896P
2360300596P
2360100796P
2360100696P
2360100596P
2360609196P
2360609496P
2360609196P
2360609496P
2360609196P
2360609496P
2360609196P
2360609496P
2253410596P
2253491496P
2251451136P
2253439096P
2251413336P
2253447096P
2253410596P
2253427196P
2251482516P
2251413026P
2253456296P
2251411036P
2253410296P
2253410496P
2253410496P
2253410496P
2253410496P
2251451136P
2253491496P
2253410396P
2253410396P
2251418026P
2253451596P
2253410596P
2253451296P
2253451296P
2251439206P
2253410596P
2253410596P
2251482596P
2251482596P
2251427406P
2251427406P
2251427406P
2251427406P
2202131800P
2285110212P
2281110491P
2281133191P
2333610691P
2333633691P
2281110291P
2281110391P
2284110291P
2284110291P
2335447791P
2335210811P
2335347713P
2302047291P
2333610591P
2281110491P
2333622691P
2281410491P
2335347713P
2283110291P
2283110291P
2333622691P
2302047391P
2272147091P
2272133191P
2335347713P
2302068391P
2281110391P
2302068391P
2281110491P
2281110491P
Description
XISTOR,NPN R SMD MMBT2907A SOT-23 DIODES
XISTOR,NPN R SMD KST2907AMTF SOT-23 FAIRCHILD
XISTOR,NPN R SMD HMBT2907A SOT23 HSMC
XISTOR,NPN R SMD MMBT2907ALT1G SOT-23 ON
XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA
XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN
XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD
XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY
XISTOR,PNP R SMD MMBT3906-NL SOT23 FAIRCHILD
FET,N-CH(SMD) 2N7002LT1G SOT-23 ON
FET,N-CH(SMD) 2N7002G SOT-23 Pyramis
RES CHIP 1/4W RC 1206 1/4 W 1.0Mohm J T
RES,CHIP 1/4 RC 1206 1/4 W 511Kohm F T
RES,CHIP 1/4 RC 1206 1/4 W 8.25Kohm F T
RES CHIP 1/4W RC 1206 1/4 W 100Kohm J T
RES,CHIP 1/4 RC 1206 1/4 W 392 ohm F T
RES,CHIP 1/4 RC 1206 1/4 W 82.5 ohm F T
PC BOARD VA721(A1) P/B FR1 160*130 1.00
CAP CER CC 1000P/1KV Y5P P=7.5 K C
CAP CER CC 0.1u/50V (Y5P) P=5.0 K T
CAP CER CC 330pF/50V P=5.0 K T
CAP ELE 105'C EC 10u/ 50V 5*11 P=5.0 T
CAP ELE 105'C EC 33u/ 50V 6.3*11 P=5.0 T
CAP CER CC 1000p/50V P=5.0 K T
CAP CER CC 1000P/1KV X7R P=5.0 K T
CAP,ELE LOW ESR 105'C EC 470u/ 25V 10*13 P=5.0 T
CAP,ELE LOW ESR 105'C EC 1000u/ 10V 8*16 P=3.5 C
CAP,MTL MEF 4700pF/50V P=5.0 J T
CAP ELE 105'C EC 1u/ 50V 5*11 P=5.0 T
CAP ELE 105'C EC 22u/ 50V 5*11 P=5.0 T
CAP CER CC 0.1u/ 50V Y5V P=5.0 Z T
CAP CER CC 1000pF/500V Y5P P=5.0 K T
CAP ELE 105'C EC 22u/ 50V 5*11 P=5.0 T
CAP,MTL MEF 0.047uF/50V P=5.0 J T
CAP CER TC 47p/50V CH P=5.0 J T
CAP,MTL MEF 0.068u/50V P=5.0 J T
Location
D912 RB
D912 RC
Q802 RA
Q802 RB
Q802 RC
Q802 RD
Q803 RA
Q803 RB
Q803 RC
Q803 RD
Q803 RE
Q804 RA
Q804 RB
Q804 RC
Q904 RA
Q904 RB
Q905 RA
Q905 RB
Q910 RA
Q910 RB
Q911 RA
Q911 RB
R803
R805
R806
R807
R808
R809
R812
R816
R824
R825
R826
R831
R832
R833
R834
R835
R836
R843
R844
R852
R901
R907
R911
R918
R922
R926
R928
R930
R931
R939
R940
R941
R942
R945
R946
U801
C806
C807
C808
C809
C810
C811
C812
C820
C821
C823
C824
C825
C826
C839
C845
C901
C902
C903
C904
C905
C906
C907
C908
C909
C910
C914
C915
C919
C920
C921
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
50
VE710s-4_VE710b-4
Item
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
ViewSonic P/N
N/A
N/A
E-C-0404-4833
E-C-0404-4833
E-C-0404-2272
E-C-0404-2272
E-C-0404-2982
E-C-0404-2982
N/A
N/A
E-IC-0401-2152
N/A
N/A
N/A
E-L-0407-0041
E-Q-0402-0555
E-Q-0402-0718
E-Q-0402-0428
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
N/A
N/A
N/A
N/A
N/A
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-1683
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
M-WR-0828-0460
M-WR-0828-0450
M-WR-0828-0450
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0450
M-WR-0828-0450
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0455
M-WR-0828-0455
M-WR-0828-0478
M-WR-0828-0455
M-WR-0828-0450
M-WR-0828-0460
M-WR-0828-0478
M-WR-0828-0451
M-WR-0828-0451
M-WR-0828-0478
M-WR-0828-0451
M-WR-0828-0455
M-WR-0828-0450
M-WR-0828-0451
M-00003554
M-00003554
M-00003554
N/A
N/A
N/A
E-R-0405-3235
N/A
N/A
E-R-0405-3230
Ref. P/N
2302068291P
2302068291P
2281110491P
2281110491P
2283110291P
2283110291P
2281133191P
2281133191P
2365328191P
2365327691P
2365321991P
2365330291P
2365330491P
2365330591P
2379101595P
2361313691P
2361316191P
2361302591P
2363227295P
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363215495P
2363231995P
2363223195P
2363230795P
2363601395P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363213695P
2363600195P
2363600195P
2363600195P
2363600195P
2428106125P
2428106075P
2428106075P
2428106100P
2428106100P
2428106100P
2428106100P
2428106075P
2428106075P
2428106100P
2428106100P
2428106100P
2428106100P
2428106050P
2428106050P
2428106100P
2428106050P
2428106075P
2428106125P
2428106100P
2428106150P
2428106150P
2428106100P
2428106150P
2428106050P
2428106075P
2428106150P
2097400301P
2097400301P
2097400301P
2239351135P
2233622095P
2233610095P
2233410295P
2239236515P
2239211815P
2233430295P
Description
LINEAR IC AP431VLA TO-92 ATC
LINEAR IC CM431GDCN TO-92 CHAMPION
LINEAR IC KA431AZTA TO-92 FAIRCHILD
LINEAR IC KA78L05AZ TO-92 FAIRCHILD
LINEAR IC HC78L05 TO-92 HC-SEMI
LINEAR IC L78L05ACZ-A/P TO-92 ST
FERRITE CORE 3.5*0.8*4.5
XISTOR,NPN R KSC945CGTA TO-92 FAIRCHILD
XISTOR,NPN R 2PC945P TO-92 PHILIPS
XISTOR,NPN R 2SC945-AP TO-92 NEC
DIODE,RECT 2A07 DO-15 1000V/2A TSC
DIODE,RECT PG208 DO-15 PEC
DIODE,RECT 20KDA60 NI
DIODE,RECT PS2010 2A/1000V DO-15 PEC
DIODE,RECT BYV26C SOD57 PHILIPS
DIODE,RECT UF4007 DO-41 1000V/1A PEC
DIODE,RECT UF4007 DO-204AL GS
DIODE,RECT 1H5G-TG-WS R-1 WILLAS
DIODE,SWITCH 1U4G 400V/1A R-1 PEC
DIODE,SWITCH 1N4148 DO-35 WILLAS
DIODE,RECT 11EQS04 NI
JUMPER 6*12.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*7.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 6*5.0mm
JUMPER 6*5.0mm
JUMPER 0.6*10.0mm
JUMPER 6*5.0mm
JUMPER 0.6*7.5mm
JUMPER 6*12.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*15.0mm
JUMPER 0.6*15.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*15.0mm
JUMPER 6*5.0mm
JUMPER 0.6*7.5mm
JUMPER 0.6*15.0mm
EYELET BSS3-1/2H T=0.25 SN 3uM
RES,PRE 1/2 S RN 1/2WS 511Kohm F T52
RES,CBN 1/2WS RD 1/2WS 22 ohm J T52
RES,CBN 1/4 S RD 1/4WS 1Kohm J T52
RES,PRE 1/4 S RN 1/4WS 3.65Kohm F T52
RES,PRE 1/4 S RN 1/4WS 1.18Kohm F T
RES,CBN 1/4 S RD 1/4WS 3.0Kohm J T52
Location
C922
C923
C924
C925
C926
C927
C930
C933
I803 RA
I803 RB
I803 RC
I902 RA
I902 RB
I902 RC
L801
Q902 RA
Q902 RB
Q902 RC
D801 RA
D801 RB
D801 RC
D801 RD
D802 RA
D802 RB
D802 RC
D802 RD
D803 RA
D803 RB
D803 RC
D803 RD
D804 RA
D804 RB
D804 RC
D804 RD
D806 RA
D806 RB
D806 RC
D807 RA
D807 RB
D809
D812
D813
D902
D903
D904
D905
D906
D913
D914
D921
D922
F901
J801
J802
J810
J811
J812
J813
J817
J822
J901
J903
J904
J905
J906
J907
J908
J909
J910
J911
J912
J913
J914
J915
J916
J950
L804
L807
PG85
PG86
PG87
R804
R820
R821
R823
R828
R830
R840
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
51
VE710s-4_VE710b-4
Item
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
ViewSonic P/N
E-R-0405-3235
E-R-0405-2309
E-00004479
E-R-0405-2744
E-R-0405-5980
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-R-0405-4534
E-R-0405-4534
E-00005729
E-C-0404-1855
E-C-0404-1855
N/A
E-C-0404-0074
N/A
E-C-0404-1856
N/A
N/A
N/A
N/A
N/A
N/A
E-FS-0410-0009
E-FS-0410-0102
E-00002343
E-PC-0411-0083
E-PC-0411-0082
E-00005306
N/A
E-L-0407-1606
N/A
N/A
E-L-0407-1606
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00001012
E-00001011
E-00001012
E-00001011
E-00001012
E-00001011
E-00001012
E-00001011
E-TH-0416-0042
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M-MS-0808-1313
N/A
M-MS-0808-1313
N/A
N/A
N/A
N/A
N/A
M-LB-0813-0002
N/A
N/A
E-L-0407-0976
E-00002347
E-00004446
N/A
N/A
N/A
M-SCW-0824-0285
M-SCW-0824-0285
C-00006196
N/A
N/A
M-MS-0808-9214
N/A
M-LB-0813-0002
CB-00006137
Ref. P/N
2233410295P
2233420295P
2235468995P
2239222025P
2239210025P
2232410195P
2232410095P
2232410095P
2239268105P
2239239205P
2239268105P
2232410095P
2232410095P
2239220015P
2239220015P
2300947481P
2287247212P
2287247212P
2357510708P
2283610391P
2335315811P
2287210312P
2275422001P
2275422001P
2275450901P
2275450901P
2363234012P
2363231212P
2213125207P
2213125211P
2365330900P
2362401800P
2362401600P
2362402300P
2365335030P
2379103500P
2371150903P
2371145301P
2379103500P
2105251400P
2105251400P
2427409121P
2404380302P
2404380302P
2404380302P
2404380302P
2361611500P
2361611100P
2361611500P
2361611100P
2361611500P
2361611100P
2361611500P
2361611100P
2229201212P
2241268816P
2239391136P
2242315595P
2242315595P
2407413100P
2407413300P
2407200991P
2407200791P
2407200991P
2407200791P
2374228009P
2374301204P
2374301200P
2374301204P
2374301200P
2056603050P
2363302800P
2363234100P
2379101491P
2361611600P
2361611800P
2072460500P
2072250104P
2072261400P
2084730082P
2084730082P
2024266901P
2053650500P
2044266301P
2051352100P
2051352000P
2056603050P
2420308002P
Description
RES,MTL 1 RS 1WS 6.8 ohm J T52
RES,PRE 1/4 S RN 1/4WS 22Kohm F T
RES,CBN 1/4 RD 1/4W 100 ohm J T52
RES,CBN 1/4 RD 1/4W 10 ohm J T
RES,PRE 1/4 S RN 1/4WS 681 ohm F T
RES,PRE 1/4 S RN 1/4WS 392 ohm F T52
X CAP MINI X2 0.47u/275V P=15.0 K C
CAP CER Y2 4700p/250V Y5V P=10.0 M K
CAP CER Y2 4700p/250V Y5V P=10.0 M K
EC HI-RIPPLE 105C 400V EC 100u/400V 18*32 P=7.5 S
CAP CER CC 0.01u/500V Z5U P=5.0 M T
CAP CER Y2 0.01uF/250V P=10.0 M C
CAP CER TC 22P/3KV SL P=7.5 J C
DIODE,RECT SR306(LF) DO-201AD MOSPEC
DIODE,RECT SB360(F9) 3A/60V DO-201AD PEC
FUSE 21502.5(2.5A) LITTEL
FUSE FUSE 2.5A/250V SG501302.5 PICO
LINEAR IC LD7552BN DIP-8 LEADTREND
PHOTO COUPLR TLP621 TOSHIBA
PHOTO COUPLR (EOL) TLP721F(D4-GR) TOSHIBA
PHOTO COUPLR TLP421 DIP4 TOSHIBA
LINEAR IC OZ9932DN PDIP-8 O2-MICRO
FERRITE CORE 0.5/3Ts 6*10
COIL,CHOKE 5uH 7.8*10 2UEW 0.65mm/12.5Ts
COIL,CHOKE ET-20 45mH 2UEW 0.26mm/55+55Ts
SPRING PLATE SPTE T=0.4MM (GROUND PLATE)
WIRE HARNESS 9P H/B 1061#24 L=120mm P=2.0
CONNECTOR 87210-0236 P=3.5 ACE OR EQUAL
FET,N-CH AP9977GJ(T-TYPE) TO-251 APEC
FET,N-CH AOU402 TO-251 AOS
THERMISTOR,PTH SCK-103 THINKING
RES,WIR 2 RW 2WS 0.68 ohm J P=7.0
RES,PRE 1/2 S RN 1/2WS 911Kohm P=7.0 F
HIGH VOLTAGE RESISTOR RD 1/2W 1.5Mohm J T52
SOCKET 0711-02-P10-9 INALWAYS
SOCKET SC-8R-F15A9 SUPERCOM
HOLDER,FUSE CQ-05T CONQUER
HOLDER,FUSE FC-05C
HOLDER,FUSE FC-05C
XFORMER,POWR ER-28 800uH 2UEW 0.4mm/26Ts
XFORMER INVERTER TLT-1167L TAILON
XFORMER INVERTER TK.2016M.101 DARFON
SERIAL LABEL VIEWSONIC LCD SERIAL LABEL
DIODE,SCHOTTKY SRF10120C ITO-220AB MOSPEC
DIODE,RECT ER1002FCT ITO-220AB PEC
FERRITE CORE 3.5*9*0.8
FET,N-CH AP03N70F-A TO-220FM APEC
FET,N-CH AP03N70F-H TO-220FM APEC
INSULATOR 30*10*0.5MM TADE:NITTO NO.5000
HEAT SINK AL60635-T5
HEAT SINK JT178QP AL6063S-75 30*15
SCREW,BND T+ M3X8(BND T+)
FRONT BEZEL VE710 ABS94HB PS7604B
LED INDIC.-FUNC VE710 PMMA 94HB
FUNCTION KEY VE710 ABS94HB AL-PLATE
NAME PLATE VIEWSONIC E015-006 3-BIRD LOGO
NAME PLATE VIEWSONIC LOGO 3 PIN VA521
FFC CABLE FFC 30P*0.5*L80mm
Location
R845
R846
R847
R905
R906
R909
R916
R917
R921
R923
R927
R932
R933
R944
R948
C801
C802
C803
C805
C813
C822
C831
C911
C916
C931
C932
D822 RA
D822 RB
F801 RA
F801 RB
I801
I802 RA
I802 RB
I802 RC
I901
L802
L803
L805
L808
PG81
PG82
P802
P901
P902
P903
P904
Q906 RA
Q906 RB
Q907 RA
Q907 RB
Q908 RA
Q908 RB
Q909 RA
Q909 RB
R802
R811
R839
R943
R947
S801 RA
S801 RB
S802 RA
S802 RB
S803 RA
S803 RB
T801
T901 RA
T901 RB
T902 RA
T902 RB
6P55
D821 RA
D821 RB
L806
Q801 RA
Q801 RB
9F01
9H02
9H03
9S02
9S03
1F01
1F02
1F03
1F04
1F05
6P54
P980
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
52
VE710s-4_VE710b-4
Item
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
ViewSonic P/N
CB-00006136
E-00006128
N/A
N/A
N/A
N/A
M-SCW-0824-6715
M-SCW-0824-0811
M-SCW-0824-0811
N/A
N/A
N/A
M-SCW-0824-6719
M-SCW-0824-0851
N/A
N/A
N/A
M-LB-0813-0959
N/A
A-VIO-0118-0034
C-00006126
PL-00005399
N/A
M-BK-0805-0070
M-SCW-0824-0812
N/A
M-LB-0813-0530
N/A
N/A
PL-00006125
N/A
PL-PD-0714-0113
N/A
N/A
N/A
M-LB-0813-0769
N/A
C-00006123
M-MS-0808-9408
C-00006124
DC-00001586
DC-00006127
DC-00004478
M-MS-0808-1316
P-00006129
N/A
N/A
M-LB-0813-0856
P-00006130
P-00006131
M-LB-0813-0002
M-LB-0813-0528
M-MS-0808-1317
Ref. P/N
2420308001P
2212007201P
2071970200P
2106656500P
2106656501P
2071970300P
2080002200P
2080003700P
2080003700P
2072457800P
2072457900P
2081430062P
2082630062P
2082340072P
2071970800P
2072458300P
2063452500P
2055613392P
2433304040P
2427501174P
2022262301P
2051352203P
2083740082P
2071869400P
2084730062P
2055636020P
2055617101P
2055132263P
2055613459P
2028258201P
2071970400P
2039819301P
2080002400P
2080004700P
2039802601P
2055613293P
2080004800P
2027258601P
2061453400P
2027258602P
2055613435P
2438501209P
2002310496P
2013222536P
2011132010P
2055613461P
2055613441P
2055613379P
2012176400P
2012176500P
2056603050P
2055103400P
2013053000P
Description
METAL FITTG VE710 PANEL SECC 0.8
HINGE VE710 -5'~ +20'
HINGE VE710 -5'~+20' FOR TL
METAL FITTG VE710 COVER SPTE T=0.3
SCREW,SPE L355 M3x6 DH NICKEL-PLATED
SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI
INSULATOR VE710 24*31*0.45 T4000
INSULATOR VE710 12*135*0.45 T4000
SCREW,(WASH) M3X6 P=0.5(TOOTH WASHER)
SCREW M3X6 P=0.5
SCREW,CSK+ SCREW CSK+ M4*7
INSULATOR 12*10*1.5 94V0 ADHESIVE
ADHESI SHEET PROM 20*10 T=3MM TAPE T4000
LABEL VSC HIGH VOLTAGE WARNING LABEL
SHIELDING FOAM W10*H10*L40mm
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
CABI BACK VE710 ABS94HB BLACK 4001
NAME PLATE V LOGO/ABS 94HB BLACK C
SCREW,BND T+ M4*8(BND T+)
BRACKET,FIX METAL PLATE 1.0MM KENSINGTON
LABEL VE710S-2 VS10047 SMALL
LABEL 10*20 HI-POT TESTED OK
LABEL VE710S-2 VS10047 CPT
LABEL VIEWSONIC Hg WARNING LABEL
METAL FITTG VE710 STAND SECC T=1.5
FOOT PAD RUBBER O20*2TMM SQUARE GRAIN
SCREW,SPE VE155/3x8 STAND
SCREW,SPE M3*4 SPECIAL THIN HEAD TYPE I
FOOT PAD JC186H20X1.6mm Rubber blac
LABEL VIEWSONIC OPEN STAND LABEL-LCD
SCREW,SPE M3.5*13 PMS/SW YLOK
BUSHING VE710 PLUG RUBBER
LABEL VIEWSONIC INSET PAGE-1280X1024
CD-OWNER GUIDE VE710S-4 WIZARD VS10047 CPT
POLYETHY BAG 250mmX350mmX0.3t ADD>PE-LD<
LABEL VIEWSONIC NO.4 STICKER
LABEL VIEWSONIC 8ms STICKER 89X58mm
LABEL VIEWSONIC CONTAINER LABEL
LABEL JK0936F WEN
Location
P981
V901
5F01
5F02 RA
5F02 RB
5F03
5F04
5F05
5F06
5F07
5F08
5F09
5F10
5F11
5F12
5F13
5F14
6P14
K101
P961
2C01
2C02
2C03
2C04
2C05
6P05
6P13
6P50
6P53
5B01
5B02
5B03
5B04
5B05
5B06
5B10
6B01
6B02
6B03
6B04
6P06
6P80
6P84
6P85
6P01
6P03
6P04
6P11
6P20
6P21
6P51
6P52
6P60
Universal number#
Q'ty
1
1
1
1
1
2
4
4
4
1
1
1
3
4
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
4
2
3
1
1
4
1
4
1
1
1
1
1
1
1
1
0.028
1
1
1
1
1
M-Model for VSA

Item
ViewSonic P/N
1
A-PC-0106-0121
2
N/A
Ref. P/N
2427130046P
2055632132P
Description
AC POWER CORD USA WALL 1.83M BLACK
LABEL VE710S-4 VS10047 (M) CPT
Location
P951
6P02
Universal number#
Q'ty
1
1
E-Model for VSE

Item
ViewSonic P/N
1
A-00006133
2
N/A
Ref. P/N
2427130047P
2055632153P
Description
AC POWER CORD GERMAN WALL 1.83M BLACK
LABEL VE710S(4) VS10047 (E) CPT
Location
P951
6P02
Universal number#
Q'ty
1
1
P-Model for VSI

Item
ViewSonic P/N
1
A-00003623
2
N/A
Ref. P/N
2427130123P
2055632151P
Description
LABEL VE710S(4) VS10047 (P) CPT
Location
P951
6P02
Universal number#
Q'ty
1
1
G-Model for VSCN

Item
ViewSonic P/N
1
MULTIPLE MATCH
2
DC-00003461
3
M-LB-0813-0862
4
N/A
5
N/A
6
N/A
7
M-LB-0813-0863
8
M-LB-0813-0864
Ref. P/N
2427130097P
2002310402P
2056606025P
2055632152P
2055613461P
2055613458P
2056606010P
2056606009P
Description
AC POWER CORD CHINA WALL 1.83M BLACK
SERIAL LABEL VS CN WARRANTY CARD SN STICKER
LABEL VE710S(4) VS10047 (G) CPT
LABEL VIEWSONIC 2005 3C LABEL ROHS
SERIAL LABEL VIEWSONIC BOX STICKER-G
SERIAL LABEL VIEWSONIC SERVICE STICKER-G
Location
P951
6P07
6P08
6P02
6P03
6P10
6P12
6P15
Universal number#
Q'ty
1
1
2
1
1
1
1
1
53
VE710s-4_VE710b-4
BOM LIST (VE710b-4 for "CMO v2.1 (8ms) Panel")

Rev: 1a
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
ViewSonic P/N
E-C-0404-3898
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-3898
N/A
N/A
N/A
N/A
E-C-0404-3898
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-3815
E-C-0404-4423
E-C-0404-4423
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-4423
E-C-0404-4423
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
E-C-0404-3815
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
E-D-0403-1779
E-D-0403-2808
N/A
E-D-0403-1892
E-00003830
Ref. P/N
2341110096P
2346147396P
2346247396P
2346147396P
2346247396P
2346147396P
2346247396P
2341110096P
2346147396P
2346247396P
2346147396P
2346247396P
2341110096P
2346147396P
2346247396P
2341147096P
2341147096P
2341147096P
2341147096P
2346410496P
2341122096P
2341122096P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2341122096P
2341122096P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2346410496P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364503996P
2364505616P
2364600196P
2364200896P
2364601396P
Description
Location
C101
C102
RA
C102
RB
C103
RA
C103
RB
C104
RA
C104
RB
C105
C106
RA
C106
RB
C107
RA
C107
RB
C108
C109
RA
C109
RB
C111
C113
C114
C115
C116
C119
C121
C122
C133
C134
C135
C136
C137
C138
C139
C140
C141
C142
C143
C145
C146
C148
C149
C151
C154
C157
C158
C160
C161
C162
C163
C166
C167
C168
C169
C170
C172
C175
C178
C179
C180
D101
RA
D101
RB
D101
RC
D103
RA
D103
RB
D103
RC
D104
RA
D104
RB
D104
RC
D105
RA
D105
RB
D106
RA
D106
RB
D106
RC
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
54
VE710s-4_VE710b-4
Item
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
ViewSonic P/N
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
E-D-0403-1779
E-D-0403-2808
E-D-0403-1779
E-D-0403-2808
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
E-D-0403-1892
E-00003830
N/A
N/A
E-IC-0401-2269
N/A
N/A
N/A
E-R-0405-6600
E-R-0405-6600
E-R-0405-6600
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00003533
E-00003533
E-00003533
N/A
N/A
N/A
N/A
N/A
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
N/A
E-Q-0402-1624
E-Q-0402-1180
N/A
E-Q-0402-1607
N/A
E-Q-0402-1607
E-Q-0402-1624
E-Q-0402-1180
Ref. P/N
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364503996P
2364505616P
2364503996P
2364505616P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2364600196P
2364200896P
2364601396P
2365930896P
2365929996P
2365915896P
2365100996P
2365812696P
2365813196P
2253200096P
2253200096P
2253200096P
2379312196P
2379312196P
2379820196P
2379820196P
2379820196P
2379820196P
2379820196P
2379520196P
2379520196P
2379520196P
2253300096P
2407630230P
2407630330P
2407630250P
2407630350P
2360100696P
2360100796P
2360100696P
2360100796P
2360100696P
2360100796P
2360501396P
2360501296P
2360301696P
2360301296P
2360100696P
2360100796P
2360100696P
2360100796P
2360301696P
2360301296P
Description
IC,DIGITAL SMD RTD2023-LF PQFP128 Realtek
IC,DIGITAL SMD MTV312GMV64 PLCC44 MYSON
IC,DIGITAL SMD 24LC16BT/SN SO-8 MICROCHIP
MEMORY IC AT24C16AN-10SU-2.7 SO-8 AMTEL
IC,LINEAR(SMD) CM2860GK1M223 SOT223 CHAMPION
IC,LINEAR(SMD) AME8805DEGTZ SOT-223 AME
SOCKET,SMD 6240-30-OR5P 0.5*30P KYOCERA
SOCKET,SMD 6240-50-0R5P 0.5*50P KYOCERA
FET,P-CH SMD AP2305GN SOT23 APEC
FET,P-CH SMD (EOL) AO3411 SOT-23 AOS
Location
D107
RA
D107
RB
D107
RC
D108
RA
D108
RB
D108
RC
D111
RA
D111
RB
D112
RA
D112
RB
D113
RA
D113
RB
D113
RC
D114
RA
D114
RB
D114
RC
D116
RA
D116
RB
D116
RC
D117
RA
D117
RB
D117
RC
D119
RA
D119
RB
D119
RC
D120
RA
D120
RB
D120
RC
D121
RA
D121
RB
D121
RC
D122
RA
D122
RB
D122
RC
I101
I104
I105
RA
I105
RB
I106
RA
I106
RB
L101
L102
L103
L104
L105
L106
L107
L108
L109
L110
L111
L112
L113
L115
P106
RA
P106
RB
P107
RA
P107
RB
Q101
RA
Q101
RB
Q102
RA
Q102
RB
Q103
RA
Q103
RB
Q104
RA
Q104
RB
Q106
RA
Q106
RB
Q107
RA
Q107
RB
Q108
RA
Q108
RB
Q109
RA
Q109
RB
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
55
VE710s-4_VE710b-4
Item
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
ViewSonic P/N
N/A
N/A
N/A
N/A
N/A
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6600
E-R-0405-6409
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6409
E-R-0405-6600
E-R-0405-6409
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6604
E-R-0405-6604
E-R-0405-6409
E-R-0405-6410
E-R-0405-6600
E-R-0405-6601
E-R-0405-6419
E-R-0405-6419
E-R-0405-6410
E-R-0405-6409
E-R-0405-6410
E-R-0405-6409
E-R-0405-6409
E-R-0405-6604
E-R-0405-6604
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6411
N/A
E-R-0405-6419
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6409
E-R-0405-6419
E-R-0405-6601
E-R-0405-6419
E-R-0405-6410
E-R-0405-6419
N/A
N/A
E-R-0405-6409
E-R-0405-6409
E-R-0405-6411
E-R-0405-6419
E-R-0405-7000
N/A
E-R-0405-6409
E-R-0405-6410
N/A
E-R-0405-6411
N/A
E-R-0405-6410
E-R-0405-6603
E-R-0405-6603
E-R-0405-6603
N/A
E-R-0405-6600
E-R-0405-6411
N/A
N/A
Ref. P/N
2259210308P
2259210308P
2259210308P
2259210308P
2259222008P
2253200096P
2253210196P
2251275096P
2253200096P
2253210196P
2253200096P
2253210196P
2251275096P
2253210196P
2253200096P
2253210196P
2251275096P
2253210196P
2253210196P
2253222296P
2253222296P
2253210196P
2253210296P
2253200096P
2253210596P
2253247296P
2253247296P
2253210296P
2253210196P
2253210296P
2253210196P
2253210196P
2253222296P
2253222296P
2251290916P
2253210196P
2253210196P
2253210396P
2251233216P
2253247296P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253210196P
2253247296P
2253210596P
2253247296P
2253210296P
2253247296P
2253300096P
2253300096P
2253210196P
2253210196P
2253210396P
2253247296P
2253222196P
2253347296P
2253210196P
2253210296P
2253300096P
2253210396P
2253227296P
2253210296P
2253222096P
2253222096P
2253222096P
2253347296P
2253200096P
2253210396P
2336310613P
2336322613P
Description
RES,CHIP NETWORKS 8P4R 1/16W 22 ohm J P=0.8
Location
RN1
RN2
RN3
RN4
RN5
R102
R103
R104
R105
R106
R107
R108
R109
R110
R111
R112
R113
R114
R116
R118
R119
R120
R124
R125
R127
R128
R129
R130
R132
R133
R134
R135
R139
R140
R142
R144
R145
R146
R148
R149
R150
R151
R152
R153
R154
R155
R156
R157
R158
R159
R161
R163
R166
R170
R176
R177
R180
R181
R182
R183
R186
R188
R189
R190
R191
R192
R193
R194
R195
R196
R197
R199
C117
C132
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
56
VE710s-4_VE710b-4
Item
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
ViewSonic P/N
N/A
N/A
E-00000999
N/A
N/A
E-00000999
E-00000999
N/A
E-00000999
E-00000999
N/A
E-Q-0402-0839
N/A
M-MS-0808-6355
N/A
N/A
E-X-0415-0119
E-X-0415-0112
N/A
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
M-SW-0815-0182
N/A
N/A
N/A
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
E-00003534
E-00003830
N/A
E-D-0403-2041
E-00003534
E-00003830
E-D-0403-2041
E-00003534
E-00003830
N/A
N/A
E-00003850
E-00003851
E-Q-0402-1180
E-Q-0402-1377
E-Q-0402-1376
E-Q-0402-1608
E-Q-0402-1378
E-Q-0402-1607
N/A
E-Q-0402-1607
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Ref. P/N
2336322613P
2336322613P
2336347613P
2336310713P
2336322613P
2336347613P
2336347613P
2336322613P
2336347613P
2336347613P
2336322613P
2361111191P
2404301112P
2404301107P
2404371008P
2202518300P
2369103601P
2369103901P
2363703891P
2403702200P
2403702200P
2403702200P
2403702200P
2403702200P
2202127900P
2427408252P
2364530016P
2364600396P
2363600696P
2364601396P
2364600396P
2363600696P
2364601396P
2364600396P
2363600696P
2364601396P
2364300896P
2364600396P
2363600696P
2364601396P
2364600396P
2363600696P
2364601396P
2360302296P
2360301096P
2360302396P
2360302496P
2360301296P
2360300396P
2360300296P
2360300896P
2360300596P
2360100796P
2360100696P
2360100596P
2360609196P
2360609496P
2360609196P
2360609496P
2360609196P
2360609496P
2360609196P
2360609496P
2253410596P
2253491496P
2251451136P
2253439096P
2251413336P
2253447096P
2253410596P
2253427196P
2251482516P
2251413026P
2253456296P
Description
CAP,MINI ELE 105'C EC 100u/ 16V 6.3*7 P=2.5 T
XISTOR,PNP R 2SA1020(Y) TO-92 TOSHIBA
CONNECTOR JST PH 9P TOP P=2.0 OR EQUAL
PCB MULTILAYER VA521(A) M/B FR4*2 100*82 1.00
LED 3 GRN/YEL
PC BOARD VA721 K/B FR1 120*21 V1.00
WIRE HARNESS 8/8P H/B 1061#26 L=250mm p=2.0
DIODE,ZENER SMD MMSZ5256B SOD-123 PEC
DIODE,SCHOTTKY(SMD) EP05Q04-TE8L 40V/0.4A IR
XISTOR,NPN R SMD MMBT2907A SOT-23 DIODES
XISTOR,NPN R SMD KST2907AMTF SOT-23 FAIRCHILD
XISTOR,NPN R SMD HMBT2907A SOT23 HSMC
XISTOR,NPN R SMD MMBT2907ALT1G SOT-23 ON
XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA
XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN
XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD
XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY
XISTOR,PNP R SMD MMBT3906-NL SOT23 FAIRCHILD
RES,CHIP 1/4 RC 1206 1/4 W 8.25Kohm F T
Location
C144
C147
C155
C156
C159
C164
C165
C171
C176
C177
C181
Q105
P101
P104
P105
U101
X101
X102
D701
S701
S702
S703
S704
S705
U701
P701
D808
D907
RA
D907
RB
D907
RC
D908
RA
D908
RB
D908
RC
D909
RA
D909
RB
D909
RC
D910
D911
RA
D911
RB
D911
RC
D912
RA
D912
RB
D912
RC
Q802
RA
Q802
RB
Q802
RC
Q802
RD
Q803
RA
Q803
RB
Q803
RC
Q803
RD
Q803
RE
Q804
RA
Q804
RB
Q804
RC
Q904
RA
Q904
RB
Q905
RA
Q905
RB
Q910
RA
Q910
RB
Q911
RA
Q911
RB
R803
R805
R806
R807
R808
R809
R812
R816
R824
R825
R826
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
57
VE710s-4_VE710b-4
Item
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
ViewSonic P/N
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00001013
E-00001013
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-C-0404-4833
E-C-0404-2982
E-C-0404-1838
E-C-0404-3243
E-C-0404-1861
N/A
N/A
N/A
N/A
N/A
N/A
E-00003555
E-C-0404-1424
E-C-0404-4833
E-C-0404-1833
E-C-0404-1815
N/A
E-C-0404-2272
E-C-0404-2272
E-C-0404-1833
N/A
E-C-0404-0287
E-C-0404-3470
N/A
N/A
N/A
N/A
E-C-0404-4833
E-C-0404-4833
N/A
N/A
E-C-0404-4833
E-C-0404-4833
E-C-0404-2272
E-C-0404-2272
E-C-0404-2982
E-C-0404-2982
N/A
N/A
E-IC-0401-2152
N/A
N/A
N/A
E-L-0407-0041
E-Q-0402-0555
E-Q-0402-0718
E-Q-0402-0428
E-D-0403-2009
Ref. P/N
2251411036P
2253410296P
2253410496P
2253410496P
2253410496P
2253410496P
2251451136P
2253491496P
2253410396P
2253410396P
2251418026P
2253451596P
2253410596P
2253451296P
2253451296P
2251439206P
2253410596P
2253410596P
2251482596P
2251482596P
2251427406P
2251427406P
2251427406P
2251427406P
2202131800P
2285110212P
2281110491P
2281133191P
2333610691P
2333633691P
2281110291P
2281110391P
2284110291P
2284110291P
2335447791P
2335210811P
2335347713P
2302047291P
2333610591P
2281110491P
2333622691P
2281410491P
2335347713P
2283110291P
2283110291P
2333622691P
2302047391P
2272147091P
2272133191P
2335347713P
2302068391P
2281110391P
2302068391P
2281110491P
2281110491P
2302068291P
2302068291P
2281110491P
2281110491P
2283110291P
2283110291P
2281133191P
2281133191P
2365328191P
2365327691P
2365321991P
2365330291P
2365330491P
2365330591P
2379101595P
2361313691P
2361316191P
2361302591P
2363227295P
Description
PC BOARD VA721(A1) P/B FR1 160*130 1.00
CAP CER CC 1000P/1KV Y5P P=7.5 K C
CAP ELE 105'C EC 10u/ 50V 5*11 P=5.0 T
CAP ELE 105'C EC 33u/ 50V 6.3*11 P=5.0 T
CAP CER CC 1000p/50V P=5.0 K T
CAP,MTL MEF 4700pF/50V P=5.0 J T
CAP ELE 105'C EC 1u/ 50V 5*11 P=5.0 T
CAP ELE 105'C EC 22u/ 50V 5*11 P=5.0 T
CAP CER CC 0.1u/ 50V Y5V P=5.0 Z T
CAP ELE 105'C EC 22u/ 50V 5*11 P=5.0 T
CAP,MTL MEF 0.047uF/50V P=5.0 J T
LINEAR IC AP431VLA TO-92 ATC
LINEAR IC CM431GDCN TO-92 CHAMPION
LINEAR IC KA431AZTA TO-92 FAIRCHILD
LINEAR IC KA78L05AZ TO-92 FAIRCHILD
LINEAR IC HC78L05 TO-92 HC-SEMI
LINEAR IC L78L05ACZ-A/P TO-92 ST
FERRITE CORE 3.5*0.8*4.5
XISTOR,NPN R KSC945CGTA TO-92 FAIRCHILD
XISTOR,NPN R 2PC945P TO-92 PHILIPS
XISTOR,NPN R 2SC945-AP TO-92 NEC
Location
R831
R832
R833
R834
R835
R836
R843
R844
R852
R901
R907
R911
R918
R922
R926
R928
R930
R931
R939
R940
R941
R942
R945
R946
U801
C806
C807
C808
C809
C810
C811
C812
C820
C821
C823
C824
C825
C826
C839
C845
C901
C902
C903
C904
C905
C906
C907
C908
C909
C910
C914
C915
C919
C920
C921
C922
C923
C924
C925
C926
C927
C930
C933
I803
RA
I803
RB
I803
RC
I902
RA
I902
RB
I902
RC
L801
Q902
RA
Q902
RB
Q902
RC
D801
RA
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
58
VE710s-4_VE710b-4
Item
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
ViewSonic P/N
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
E-D-0403-2009
E-D-0403-1531
E-D-0403-1671
N/A
N/A
N/A
N/A
N/A
N/A
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-1683
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
E-D-0403-0531
M-WR-0828-0460
M-WR-0828-0450
M-WR-0828-0450
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0450
M-WR-0828-0450
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0478
M-WR-0828-0455
M-WR-0828-0455
M-WR-0828-0478
M-WR-0828-0455
M-WR-0828-0450
M-WR-0828-0460
M-WR-0828-0478
M-WR-0828-0451
M-WR-0828-0451
M-WR-0828-0478
M-WR-0828-0451
M-WR-0828-0455
M-WR-0828-0450
M-WR-0828-0451
M-00003554
M-00003554
M-00003554
N/A
N/A
N/A
E-R-0405-3235
N/A
N/A
E-R-0405-3230
E-R-0405-3235
E-R-0405-2309
E-00004479
E-R-0405-2744
E-R-0405-5980
Ref. P/N
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363227295P
2363221195P
2363224295P
2363233795P
2363215495P
2363231995P
2363223195P
2363230795P
2363601395P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363600195P
2363213695P
2363600195P
2363600195P
2363600195P
2363600195P
2428106125P
2428106075P
2428106075P
2428106100P
2428106100P
2428106100P
2428106100P
2428106075P
2428106075P
2428106100P
2428106100P
2428106100P
2428106100P
2428106050P
2428106050P
2428106100P
2428106050P
2428106075P
2428106125P
2428106100P
2428106150P
2428106150P
2428106100P
2428106150P
2428106050P
2428106075P
2428106150P
2097400301P
2097400301P
2097400301P
2239351135P
2233622095P
2233610095P
2233410295P
2239236515P
2239211815P
2233430295P
2233410295P
2233420295P
2235468995P
2239222025P
2239210025P
Description
DIODE,RECT BYV26C SOD57 PHILIPS
DIODE,RECT UF4007 DO-41 1000V/1A PEC
DIODE,RECT UF4007 DO-204AL GS
DIODE,RECT 1H5G-TG-WS R-1 WILLAS
DIODE,SWITCH 1U4G 400V/1A R-1 PEC
DIODE,RECT 11EQS04 NI
JUMPER 6*12.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*7.5mm
JUMPER 0.6*7.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*10.0mm
JUMPER 6*5.0mm
JUMPER 6*5.0mm
JUMPER 0.6*10.0mm
JUMPER 6*5.0mm
JUMPER 0.6*7.5mm
JUMPER 6*12.5mm
JUMPER 0.6*10.0mm
JUMPER 0.6*15.0mm
JUMPER 0.6*15.0mm
JUMPER 0.6*10.0mm
JUMPER 0.6*15.0mm
JUMPER 6*5.0mm
JUMPER 0.6*7.5mm
JUMPER 0.6*15.0mm
RES,PRE 1/2 S RN 1/2WS 511Kohm F T52
RES,PRE 1/4 S RN 1/4WS 1.18Kohm F T
RES,MTL 1 RS 1WS 6.8 ohm J T52
Location
D801
RB
D801
RC
D801
RD
D802
RA
D802
RB
D802
RC
D802
RD
D803
RA
D803
RB
D803
RC
D803
RD
D804
RA
D804
RB
D804
RC
D804
RD
D806
RA
D806
RB
D806
RC
D807
RA
D807
RB
D809
D812
D813
D902
D903
D904
D905
D906
D913
D914
D921
D922
F901
J801
J802
J810
J811
J812
J813
J817
J822
J901
J903
J904
J905
J906
J907
J908
J909
J910
J911
J912
J913
J914
J915
J916
J950
L804
L807
PG85
PG86
PG87
R804
R820
R821
R823
R828
R830
R840
R845
R846
R847
R905
R906
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
59
VE710s-4_VE710b-4
Item
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
ViewSonic P/N
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-R-0405-4534
E-R-0405-4534
E-00005729
E-C-0404-1855
E-C-0404-1855
N/A
E-C-0404-0074
N/A
E-C-0404-1856
N/A
N/A
N/A
N/A
N/A
N/A
E-FS-0410-0009
E-FS-0410-0102
E-00002343
E-PC-0411-0083
E-PC-0411-0082
E-00005306
N/A
E-L-0407-1606
N/A
N/A
E-L-0407-1606
N/A
N/A
N/A
N/A
N/A
N/A
N/A
E-00001012
E-00001011
E-00001012
E-00001011
E-00001012
E-00001011
E-00001012
E-00001011
E-TH-0416-0042
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M-MS-0808-1313
N/A
M-MS-0808-1313
N/A
N/A
N/A
N/A
N/A
M-LB-0813-0002
N/A
N/A
E-L-0407-0976
E-00002347
E-00004446
N/A
N/A
N/A
Ref. P/N
2232410195P
2232410095P
2232410095P
2239268105P
2239239205P
2239268105P
2232410095P
2232410095P
2239220015P
2239220015P
2300947481P
2287247212P
2287247212P
2357510708P
2283610391P
2335315811P
2287210312P
2275422001P
2275422001P
2275450901P
2275450901P
2363234012P
2363231212P
2213125207P
2213125211P
2365330900P
2362401800P
2362401600P
2362402300P
2365335030P
2379103500P
2371150903P
2371145301P
2379103500P
2105251400P
2105251400P
2427409121P
2404380302P
2404380302P
2404380302P
2404380302P
2361611500P
2361611100P
2361611500P
2361611100P
2361611500P
2361611100P
2361611500P
2361611100P
2229201212P
2241268816P
2239391136P
2242315595P
2242315595P
2407413100P
2407413300P
2407200991P
2407200791P
2407200991P
2407200791P
2374228009P
2374301204P
2374301200P
2374301204P
2374301200P
2056603050P
2363302800P
2363234100P
2379101491P
2361611600P
2361611800P
2072460500P
2072250104P
2072261400P
Description
RES,CBN 1/4 RD 1/4W 100 ohm J T52
RES,PRE 1/4 S RN 1/4WS 392 ohm F T52
X CAP MINI X2 0.47u/275V P=15.0 K C
CAP CER Y2 4700p/250V Y5V P=10.0 M K
CAP CER Y2 4700p/250V Y5V P=10.0 M K
EC HI-RIPPLE 105C 400V EC 100u/400V 18*32 P=7.5 S
CAP CER CC 0.01u/500V Z5U P=5.0 M T
CAP CER Y2 0.01uF/250V P=10.0 M C
DIODE,RECT SR306(LF) DO-201AD MOSPEC
DIODE,RECT SB360(F9) 3A/60V DO-201AD PEC
FUSE 21502.5(2.5A) LITTEL
FUSE FUSE 2.5A/250V SG501302.5 PICO
LINEAR IC LD7552BN DIP-8 LEADTREND
PHOTO COUPLR TLP621 TOSHIBA
PHOTO COUPLR (EOL) TLP721F(D4-GR) TOSHIBA
PHOTO COUPLR TLP421 DIP4 TOSHIBA
LINEAR IC OZ9932DN PDIP-8 O2-MICRO
COIL,CHOKE 5uH 7.8*10 2UEW 0.65mm/12.5Ts
COIL,CHOKE ET-20 45mH 2UEW 0.26mm/55+55Ts
WIRE HARNESS 9P H/B 1061#24 L=120mm P=2.0
THERMISTOR,PTH SCK-103 THINKING
RES,WIR 2 RW 2WS 0.68 ohm J P=7.0
RES,PRE 1/2 S RN 1/2WS 911Kohm P=7.0 F
SOCKET 0711-02-P10-9 INALWAYS
SOCKET SC-8R-F15A9 SUPERCOM
HOLDER,FUSE FC-05C
HOLDER,FUSE FC-05C
XFORMER,POWR ER-28 800uH 2UEW 0.4mm/26Ts
DIODE,SCHOTTKY SRF10120C ITO-220AB MOSPEC
DIODE,RECT ER1002FCT ITO-220AB PEC
FERRITE CORE 3.5*9*0.8
FET,N-CH AP03N70F-A TO-220FM APEC
FET,N-CH AP03N70F-H TO-220FM APEC
INSULATOR 30*10*0.5MM TADE:NITTO NO.5000
HEAT SINK AL60635-T5
HEAT SINK JT178QP AL6063S-75 30*15
Location
R909
R916
R917
R921
R923
R927
R932
R933
R944
R948
C801
C802
C803
C805
C813
C822
C831
C911
C916
C931
C932
D822
RA
D822
RB
F801
RA
F801
RB
I801
I802
RA
I802
RB
I802
RC
I901
L802
L803
L805
L808
PG81
PG82
P802
P901
P902
P903
P904
Q906
RA
Q906
RB
Q907
RA
Q907
RB
Q908
RA
Q908
RB
Q909
RA
Q909
RB
R802
R811
R839
R943
R947
S801
RA
S801
RB
S802
RA
S802
RB
S803
RA
S803
RB
T801
T901
RA
T901
RB
T902
RA
T902
RB
6P55
D821
RA
D821
RB
L806
Q801
RA
Q801
RB
9F01
9H02
9H03
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
60
VE710s-4_VE710b-4
Item
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
ViewSonic P/N
M-SCW-0824-0285
M-SCW-0824-0285
N/A
N/A
N/A
M-MS-0808-9214
N/A
M-LB-0813-0002
CB-00006137
CB-00006136
E-00006128
N/A
N/A
N/A
N/A
M-SCW-0824-6715
M-SCW-0824-0811
M-SCW-0824-0811
N/A
N/A
N/A
M-SCW-0824-6719
M-SCW-0824-0851
N/A
N/A
N/A
M-LB-0813-0959
N/A
A-VIO-0118-0034
C-00006202
M-MS-0808-9396
N/A
M-BK-0805-0070
M-SCW-0824-0812
N/A
M-LB-0813-0530
N/A
N/A
PL-00006199
N/A
PL-PD-0714-0113
N/A
N/A
N/A
M-LB-0813-0769
N/A
C-00006123
M-MS-0808-9408
C-00006124
DC-00001586
DC-00006200
DC-00004478
M-MS-0808-1316
N/A
N/A
N/A
M-LB-0813-0856
P-00006130
P-00006131
M-LB-0813-0002
M-LB-0813-0528
M-MS-0808-1317
Ref. P/N
2084730082P
2084730082P
2024266902P
2053650500P
2044266301P
2051352100P
2051352000P
2056603050P
2420308002P
2420308001P
2212007201P
2071970200P
2106656500P
2106656501P
2071970300P
2080002200P
2080003700P
2080003700P
2072457800P
2072457900P
2081430062P
2082630062P
2082340072P
2071970800P
2072458300P
2063452500P
2055613392P
2433304040P
2427501174P
2022262302P
2051352202P
2083740082P
2071869400P
2084730062P
2055636021P
2055617101P
2055132261P
2055613459P
2028258202P
2071970400P
2039819301P
2080002400P
2080004700P
2039802601P
2055613293P
2080004800P
2027258601P
2061453400P
2027258602P
2055613435P
2438501210P
2002310496P
2013222536P
2011132011P
2055613461P
2055613441P
2055613379P
2012176400P
2012176500P
2056603050P
2055103400P
2013053000P
Description
FRONT BEZEL VE710B-2 ABS94HB PANTONE 432C
LED INDIC.-FUNC VE710 PMMA 94HB
FUNCTION KEY VE710 ABS94HB AL-PLATE
NAME PLATE VIEWSONIC E015-006 3-BIRD LOGO
NAME PLATE VIEWSONIC LOGO 3 PIN VA521
METAL FITTG VE710 PANEL SECC 0.8
HINGE VE710 -5'~ +20'
HINGE VE710 -5'~+20' FOR TL
SCREW,SPE L355 M3x6 DH NICKEL-PLATED
INSULATOR VE710 24*31*0.45 T4000
INSULATOR VE710 12*135*0.45 T4000
SCREW,(WASH) M3X6 P=0.5(TOOTH WASHER)
SCREW M3X6 P=0.5
SCREW,CSK+ SCREW CSK+ M4*7
INSULATOR 12*10*1.5 94V0 ADHESIVE
ADHESI SHEET PROM 20*10 T=3MM TAPE T4000
LABEL VSC HIGH VOLTAGE WARNING LABEL
SHIELDING FOAM W10*H10*L40mm
I/O CABLE D15/C13 20276(3+6) 1.83M BLK
CABI BACK VE710B-2 ABS94HB PANTONE 432C
NAME PLATE NAME PLATE VIEWSONIC E015-027
SCREW,BND T+ M4*8(BND T+)
BRACKET,FIX METAL PLATE 1.0MM KENSINGTON
LABEL VE710B-2 VS10047 SMALL
LABEL 10*20 HI-POT TESTED OK
LABEL VE710B-4 VS10047 CPT
LABEL VIEWSONIC Hg WARNING LABEL
METAL FITTG VE710 STAND SECC T=1.5
FOOT PAD RUBBER O20*2TMM SQUARE GRAIN
SCREW,SPE VE155/3x8 STAND
SCREW,SPE M3*4 SPECIAL THIN HEAD TYPE I
FOOT PAD JC186H20X1.6mm Rubber blac
LABEL VIEWSONIC OPEN STAND LABEL-LCD
SCREW,SPE M3.5*13 PMS/SW YLOK
BUSHING VE710 PLUG RUBBER
LABEL VIEWSONIC INSET PAGE-1280X1024
CD-OWNER GUIDE VE710B-4 WIZARD VS10047 CPT
POLYETHY BAG 250mmX350mmX0.3t ADD>PE-LD<
LABEL VIEWSONIC 8ms STICKER 89X58mm
LABEL VIEWSONIC CONTAINER LABEL
LABEL JK0936F WEN
Location
9S02
9S03
1F01
1F02
1F03
1F04
1F05
6P54
P980
P981
V901
5F01
5F02
RA
5F02
RB
5F03
5F04
5F05
5F06
5F07
5F08
5F09
5F10
5F11
5F12
5F13
5F14
6P14
K101
P961
2C01
2C02
2C03
2C04
2C05
6P05
6P13
6P50
6P53
5B01
5B02
5B03
5B04
5B05
5B06
5B10
6B01
6B02
6B03
6B04
6P06
6P80
6P84
6P85
6P01
6P03
6P04
6P11
6P20
6P21
6P51
6P52
6P60
Universal number#
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
4
4
4
1
1
1
3
4
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
4
2
3
1
1
4
1
4
1
1
1
1
1
1
1
1
0.028
1
1
1
1
1
Ref. P/N
2427130046P
2055632130P
Description
AC POWER CORD USA WALL 1.83M BLACK
LABEL VE710B-4 VS10047 (M) CPT
Location
Universal number#
P951
6P02
Q'ty
1
1
Universal number#
Q'ty
1
1
M-Model for VSA

Item
1
2
ViewSonic P/N
A-00005362
N/A
E-Model for VSE

Item
1
2
ViewSonic P/N
A-00006133
N/A
Ref. P/N
Description
2427130047P AC POWER CORD GERMAN WALL 1.83M BLACK
2055632156P LABEL VE710B(4) VS10047 (E) CPT
Location
P951
6P02
P-Model for VSI
61
VE710s-4_VE710b-4
Item
Item
1
2
ViewSonic P/N
ViewSonic P/N
A-00003623
N/A
Ref. P/N
Description
Ref. P/N
Description
2427130123P AC POWER CORD TAIWAN WALL 1.83M BLACK
2055632154P LABEL VE710B(4) VS10047 (P) CPT
Location
Location
Universal number#
Universal number#
Q'ty
Q'ty
1
1
Universal number#
Q'ty
1
1
2
1
1
1
1
P951
6P02
G-Model for VSCN

Item
1
2
3
4
5
6
7
ViewSonic P/N
A-00006132
DC-00003461
M-LB-0813-0862
N/A
N/A
M-LB-0813-0863
M-LB-0813-0864
Ref. P/N
2427130097P
2002310402P
2056606025P
2055632155P
2055613458P
2056606010P
2056606009P
Description
AC POWER CORD CHINA WALL 1.83M BLACK
SERIAL LABEL VS CN WARRANTY CARD SN STICKER
LABEL VE710B(4) VS10047 (G) CPT
LABEL VIEWSONIC 2005 3C LABEL ROHS
SERIAL LABEL VIEWSONIC BOX STICKER-G
SERIAL LABEL VIEWSONIC SERVICE STICKER-G
Location
P951
6P07
6P08
6P02
6P10
6P12
6P15
62
VE710s-4_VE710b-4
8. Exploded Diagram And Spare Parts List (VE710s-4/VE710b-4)

FIG.1
12
7-1
15 X2
20 X4
7-2
NOTE.1
13-1
7-3
13-2
MAIN PCB ASS'Y
17
X4
18
29
15 X2
11 X3
10 X2
2-1
16 X4
2-2
2-3
POWER PCB ASS'Y

3-1
3-2
3-3
X5
NOTE.1
5
1-1
1-2
22 X2
1-3
21
23
19
22 X2
19
23
4
X2
14
FIG.1
6
X2
KEYPAD PCB ASS'Y

19
14
63
VE710s-4_VE710b-4
LCD PANEL
27
PANEL SOURCE:
CPT CLAA170EA08Q
(8ms)
CM0 M170E5-L09
(8ms)
28
25
P104
P901
P802
P105
P101
MAIN PCB
(M-star scaler)
POWER PCB
P107
P106
P107
P105
P102
MAIN PCB
(Realtek scaler)
P104
P101
24
P701
P902
KEYPAD PCB
I/O CABLE
64
VE710s-4_VE710b-4
26
LCD PANEL
PANEL SOURCE:
CPT CLAA170EA08QV
(8ms)
CMO M170E5-L09 (8ms)
BLU
RED
27
25
P902
P901
P105
P802
P106
MAIN PCB
(Realtek scaler)
POWER PCB
P104
P101
24
BLU
RED
P903
P701
P904
KEYPAD PCB
I/O CABLE
65
VE710s-4_VE710b-4
26
EXPLODED PARTS LIST (VE710s-4)

Rev: 1a
Item
1-1
1-2
1-3
2-1
2-2
2-2
3-1
3-2
3-3
4
5
6
7-1
7-2
7-3
8
9
10
11
12
11-1
11-2
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
ViewSonic P/N
C-FP-0301-0980
C-FP-0301-0978
C-FP-0301-0976
C-BC-0302-0587
C-BC-0302-0588
C-BC-0302-0587
M-MS-0808-9215
M-MS-0808-9357
M-MS-0808-9215
M-SCW-0824-0848
M-BK-0805-0070
M-SCW-0824-0812
PL-PS-0715-0990
PL-PS-0715-0991
PL-PS-0715-0990
M-BK-0805-0071
PL-PD-0714-0113
M-SCW-0824-6716
M-SCW-0824-0849
M-BK-0805-0072
M-MS-0808-9354
M-MS-0808-9355
M-BK-0805-0073
M-SCW-0824-6715
M-SCW-0824-6717
M-SCW-0824-0850
M-SCW-0824-6717
M-SCW-0824-6719
M-SCW-0824-0851
M-BK-0805-0074
M-BK-0805-0070
M-CV-0830-0300
M-MS-0808-9359
M-MS-0808-9360
A-VIO-0118-0034
M-FC-0809-0798
CB-00000801
M-FC-0809-0788
E-00006128
E-00003456
Ref. P/N
2603307568
2603307569
2603307576
2022262301
2022262302
2022262301
2051352200
2051352201
2051352200
2083740082
2071869400
2084730062
2028258201
2028258202
2028258201
2071970400
2039819301
2080002400
2080004700
2071970200
2106656500
2106656501
2071970300
2080002200
2081430062
2082730058
2081430062
2082630062
2082340072
2071970800
2071869400
2027258601
2427408252
2427409121
2427501174
2420308002
2420316301
2420308001
2212007201P
2212008000
FRONT BEZEL
FRONT BEZEL
FRONT BEZEL
CABI BACK
CABI BACK
CABI BACK
NAME PLATE
NAME PLATE
NAME PLATE
SCREW,BND T+
BRACKET,FIX
SCREW,BND T+
STAND
STAND
STAND
METAL FITTG
FOOT PAD
SCREW,SPE
SCREW,SPE
METAL FITTG
HINGE
HINGE
METAL FITTG
SCREW,SPE
SCREW,(WASH)
SCREW,BND+
SCREW,(WASH)
SCREW
SCREW,CSK+
METAL FITTG
SCREW,SPE
DUST COVER
WIRE HARNESS
WIRE HARNESS
I/O CABLE
FFC CABLE
FFC CABLE
FFC CABLE
LCD PANEL
LCD PANEL
Description
VE710 ABS94HB PS7604B
VE710B-2 ABS94HB PANTONE 432C
VA721 ABS 94HB PS7604B
VE710 ABS94HB BLACK 4001
VIEWSONIC E015-017 VE710s-4
NAME PLATE VIEWSONIC E015-019 VE710b-4
VIEWSONIC E015-017 VA721
M4*8(BND T+)
METAL PLATE 1.0MM KENSINGTON
M3X6(BND T+)
VE710s-4 ABS94HB BLACK 4001
VE710 STAND SECC T=1.5
RUBBER O20*2TMM SQUARE GRAIN
VE155/3x8 STAND
M3*4 SPECIAL THIN HEAD TYPE I
VE710 PANEL SECC 0.8
VE710 -5~ +20
VE710 -5~+20 FOR TL
VE710 COVER SPTE T=0.3
L355 M3x6 DH NICKEL-PLATED
M3X6 P=0.5(TOOTH WASHER)
JP166K M3X5 Ni BND+
M3X6 P=0.5
SCREW CSK+ M4*7
M3.5*13 PMS/SW YLOK
VE710 ABS94HB AL
8P H/B 1061#26 L=250mm P=2.0
9P H/B 1061#24 L=120mm P=2.0
D15/C13 20276(3+6) 1.83M BLK
30P*0.5*L80mm CPT
FFC 30P*1.0mm*L165mm CMO
80L*25.5W*0.32T 0.3C*0.5P*50N CPT only
CLAA170EA08Q Ver1.1 8ms CPT
M170E5-L09 Ver1.0 CMO
Q'ty
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
5
2
3
1
1
1
2
4
4
4
1
3
4
1
4
2
1
1
1
1
1
1
1
1
66
VE710s-4_VE710b-4
EXPLODED PARTS LIST (VE710b-4)

Rev: 1a
Description
Item
ViewSonic P/N
Ref. P/N
Q'ty
1-1
C-FP-0301-0980
2603307568
FRONT BEZEL
VE710 ABS94HB PS7604B
1-2
C-FP-0301-0978
2603307569
FRONT BEZEL
1-3
C-FP-0301-0976
2603307576
FRONT BEZEL
VA721 ABS 94HB PS7604B
2-1
C-BC-0302-0587
2022262301
CABI BACK
2-2
C-BC-0302-0588
2022262302
CABI BACK
2-2
C-BC-0302-0587
2022262301
CABI BACK
3-1
M-MS-0808-9215
2051352200
NAME PLATE
VIEWSONIC E015-017 VE710s-4
3-2
M-MS-0808-9357
2051352201
NAME PLATE
NAME PLATE VIEWSONIC E015-019 VE710b-4
3-3
M-MS-0808-9215
2051352200
NAME PLATE
VIEWSONIC E015-017 VA721
M-SCW-0824-0848
2083740082
SCREW,BND T+
M4*8(BND T+)
M-BK-0805-0070
2071869400
BRACKET,FIX
METAL PLATE 1.0MM KENSINGTON
M-SCW-0824-0812
2084730062
SCREW,BND T+
M3X6(BND T+)
7-1
PL-PS-0715-0990
2028258201
STAND
VE710s-4 ABS94HB BLACK 4001
7-2
PL-PS-0715-0991
2028258202
STAND
7-3
PL-PS-0715-0990
2028258201
STAND
M-BK-0805-0071
2071970400
METAL FITTG
VE710 STAND SECC T=1.5
PL-PD-0714-0113
2039819301
FOOT PAD
RUBBER O20*2TMM SQUARE GRAIN
10
M-SCW-0824-6716
2080002400
SCREW,SPE
VE155/3x8 STAND
11
M-SCW-0824-0849
2080004700
SCREW,SPE
M3*4 SPECIAL THIN HEAD TYPE I
12
M-BK-0805-0072
2071970200
METAL FITTG
VE710 PANEL SECC 0.8
11-1
M-MS-0808-9354
2106656500
HINGE
VE710 -5~ +20
11-2
M-MS-0808-9355
2106656501
HINGE
VE710 -5~+20 FOR TL
14
M-BK-0805-0073
2071970300
METAL FITTG
15
M-SCW-0824-6715
2080002200
SCREW,SPE
L355 M3x6 DH NICKEL-PLATED
16
M-SCW-0824-6717
2081430062
SCREW,(WASH)
17
M-SCW-0824-0850
2082730058
SCREW,BND+
JP166K M3X5 Ni BND+
18
M-SCW-0824-6717
2081430062
SCREW,(WASH)
19
M-SCW-0824-6719
2082630062
SCREW
M3X6 P=0.5
20
M-SCW-0824-0851
2082340072
SCREW,CSK+
SCREW CSK+ M4*7
21
M-BK-0805-0074
2071970800
METAL FITTG
22
M-BK-0805-0070
2071869400
SCREW,SPE
M3.5*13 PMS/SW YLOK
23
M-CV-0830-0300
2027258601
DUST COVER
VE710 ABS94HB AL
24
M-MS-0808-9359
2427408252
WIRE HARNESS
8P H/B 1061#26 L=250mm P=2.0
25
M-MS-0808-9360
2427409121
WIRE HARNESS
9P H/B 1061#24 L=120mm P=2.0
26
A-VIO-0118-0034
2427501174
I/O CABLE
D15/C13 20276(3+6) 1.83M BLK
M-FC-0809-0798
2420308002
FFC CABLE
30P*0.5*L80mm CPT
CB-00000801
2420316301
FFC CABLE
FFC 30P*1.0mm*L165mm CMO
2420308001
FFC CABLE
27
28
M-FC-0809-0788
80L*25.5W*0.32T 0.3C*0.5P*50N CPT only
29
E-00006128
2212007201P LCD PANEL
CLAA170EA08Q Ver1.1 8ms CPT
30
E-00003456
2212008000
M170E5-L09 Ver1.0 CMO
LCD PANEL
67
VE710s-4_VE710b-4
9. Block Diagram (VE710s-4/VE710b-4/VA721 M-star Scaler CPT Panel)

SWITCHING
POWER SUPPLY
AC 110~220V
INPUT
12V
I101,I102
DC / DC
3V3/5V
3V3
ONBACKLITE
2V5
ADJBACKLITE
I105
MST8116A
SXGA
RSDS
SCALAR
G
B
H-Sync
V-Sync
PB [0,19]
GBO [0,4] OSP,ESP,0INV
SCL
INT
SDA
DDC-SDA
I106
MTV312M64
DDC-SCL
HW RESET
ONBACKLITE
SDA
SCL
KEY- PAD LED
3V3/5V
PANEL POWER
3V3/5V
PA [0,19]
CSZ
I107
24LC16
EEPROM
I901 OZ9RR
INVERTER
12V
68
VE710s-4_VE710b-4
LCD PANEL
12V
9. Block Diagram (VE710s-4/VE710b-4/VA721 Realtek Scaler CPT PANEL)

SWITCHING
POWER SUPPLY
AC 110~220V
INPUT
12V
I106,I107
DC / DC
3V3/5V
3V3
ONBACKLITE
2V5
ADJBACKLITE
I101
RTD2023
SXGA
RSDS
SCALAR
G
B
H-Sync
V-Sync
PB [0,19]
GBO [0,4] OSP,ESP,0INV
SCL
SDA
DDC-SDA
I104
MTV312M64
DDC-SCL
3V3/5V
PANEL POWER
3V3/5V
PA [0,19]
CSZ
I105
24LC16
EEPROM
HW RESET
ONBACKLITE
SDA
SCL
KEY- PAD LED
I901 OZ9RR
INVERTER
12V
69
VE710s-4_VE710b-4
LCD PANEL(CPT)
12V
9. Block Diagram (VE710s-4/VE710b-4/VA721 Realtek Scaler CMO Panel)

SWITCHING
POWER SUPPLY
AC 110~220V
INPUT
12V
I106I107
DC / DC
3V3/5V
3V3
ONBACKLITE
2V5
ADJBACKLITE
I101
RTD2023
SXGA
LVDS
SCALAR
G
B
H-Sync
V-Sync
RXO 09
SCL
INT
SDA
DDC-SDA
I104
MTV312M64
DDC-SCL
HW RESET
ONBACKLITE
SDA
SCL
KEY- PAD LED
3V3/5V
PANEL POWER
3V3/5V
RXE 09
CSZ
I105
24LC16
EEPROM
I901 OZ9RR
INVERTER
12V
70
VE710s-4_VE710b-4
LCD PANEL(CMO)
12V
10. Schematic Diagrams (VE710s-4/VE710b-4/VA721) 10.1. Power (Realtek Scaler CPT Panel)
Q104
AP2305
2
12V
VLCD
R180
VLCD_12V
10K
4K7
R182
R183
220
4.7K 0805
3
Q106
2
MMBT3904
onPanel_3V3
R181
R184
3V3_PANEL
Q105
2SA1020
2
onPanel_12V
R185
NC
Q105, Q109, R181, R183, R185
NC (AU )
R196
4.7K 0805
3
Q109
2
MMBT3904
NC
C168
100nF
C169
100nF
12V
P105
1 L111
2
3
4 L112
5 L113
6
7
8
9
12V
200R 2A
onBacklight
3V3
3V3_PANEL
200R 2A
200R 2A
C164
AdjBACKLITE
C171
C172
100nF
2V5
I106
R188 1K
R187 NC/1K8
C173 C174
NC/100nF
+ NC/100nF
3V3
C170
100nF
5.0V
(AU)
Mute
Volume
C185
CON9
SOT-223
R186 100
C166
47uF/16V
VIN
ADJ
VOUT
3
C165
CM2860-2.5V
100nF
47uF/16V
C167
100nF
22uF/16V
C175
100nF
NC/22uF/16V
3V3
R189 0R 0805
3V3
Q107
VCC3V3
MMBT3906
3
VCPU
I107
3
1
C176
C178
R191
C180
C181
2K7
100nF
22uF/16V
1
R192
47uF/16V
3
Q108
2MMBT3906
D116
D117
PC5V
PC5V
1K
IN4148
IN4148
D116,D117 0 OHM 1206 (AU)
GND
VO
VO
3DVCC
C177
C179
NC
R190
10K
IN
71
VE710s-4_VE710b-4
100nF
47uF/16V
100nF
RTD 3DVCC
TMDS_3AVCC
ADC_ 3AVCC
RTD 3PVCC
10.1. Power (Realtek Scaler CMO Panel)
12V
P105
1
2
3
4
5
6
7
8
9
L111
200R 2A
R186 100
L112
L113
200R 2A
200R 2A
onBacklight
3V3_5V
3V3_5V_PANEL
C170
100nF
R188 1K
Mute
C174
100nF
CON9
C175
100nF
C168
100nF
VLCD
1
G
R180
AdjBacklight
C171
Q104
AP2305
3
D
S
2
3V3_5V_PANEL
10K
C172
100nF
22uF/16V
C169
100nF
R182
220
Volume
R187 NC/1K8
C173
NC/100nF
onPanel_3v3
C185
NC/22uF/16V
R184
NC
VCC3V3
Q107
3V3_5V
MMBT3906
3
I106
2V5
VCPU
C164
VIN
ADJ
C166
3
C165
C167
VOUT
47uF/16V
R190
NC/10K
R191
C180
C181
2K7
100nF
22uF/16V
CM2860-2.5V
100nF
47uF/16V
100nF
3
Q108
2MMBT3906
D116
R192
D117
PC5V
R189 NC/0R 0805
PC5V
1K
IN4148
IN4148
3V3_5V
VCC3V3
I107
R115
3
1
NC
C176
C178
IN
VO
GND
VO
2
C177
C179
RC1117
47uF/16V
100nF
47uF/16V
15'
17'
3 (C)
1 (B)
2 (E)
72
VE710s-4_VE710b-4
R189 0R0805, I107 NC

R189 NC, I107 RC1117
100nF
3
Q106
2
MMBT3904
10.2. Input (Realtek Scaler CPT Panel)

VCC3V3
D119
IN4148
L105
120 R
V_SYNC
R120
100
D109
R118
NC/5V6
DDC_CLK
D120
IN4148
VSYNC
C113
47PF
C0603
2K2
C115
D112
47PF
VCC3V3
5V6
L104
D111
DDC_DAT
D121
IN4148
R116
C114
D110
47PF
NC/5V6
100
HSYNC
R119
C111
47PF
2K2
C0603
D122
IN4148
5V6
120 R
H_SYNC
VCC3V3
R101
NC
R105
0R 0603
ST_DET1
R197
0R 0603
L101
R103
100
C102
47nF
BLUE+
CB
D102
NC
R104
75
P101
1
2
3
4
5
6
7
8
9
10
11
12
13
R102
0R 0603
0R 0603
C101
10pF
R106
100
SCL_VGA
C103
47nF
BLUE-
SDA_VGA
CB
CB-
V_Sync
CB-
H_Sync
VGA_CON
PC5V
PC5V
BLUE-
L102
R107
0R 0603
0R 0603
R108
100
C104
47nF
GREEN+
CG
BLUE+
GREENGREEN+
RED-
R109
75
5V6
C105
10pF
RED+
R110
100
C106
47nF
GREEN-
CG-
VCC3V3
CON13
L103
R111
0R 0603
0R 0603
R112
100
D101
IN4148
D103
IN4148
CR
R113
75
D104
IN4148
D106
IN4148
D107
IN4148
D108
IN4148
73
VE710s-4_VE710b-4
CR
C108
10pF
R114
100
RED-
CG-
C107
47nF
RED+
CG
D105
C109
47nF
CR-
CR-
10.2. Input (Realtek Scaler CMO Panel)
DDC_CLK
C115
D112
47PF
L105
120 R
R120
V_SYNC
5V6
VSYNC
R118
D121
100
C113
47PF
2K2
3V6
C0603
DDC_DAT
D111
C114
VCC3V3
47PF
L104
5V6
R101
NC
120 R
R116
H_SYNC
HSYNC
R105 0
R119
ST_DET1
R197
100
2K2
D102
C111
47PF
D122
C0603
3V6
NC
P101
1
2
3
4
5
6
7
8
9
10
11
12
13
SCL_VGA
L101
0_0603
SDA_VGA
V_Sync
H_Sync
R102
0
R103
100
C102
47nF
BLUE+
CB
VGA_CON
PC5V
PC5V
BLUEBLUE+
GREENGREEN+
R104
75
C101
NC
D105
REDRED+
5V6
R106
100
C103
47nF
BLUE-
CBL102
0_0603
VCC3V3
R107
0
R108
100
CG
R109
75
D101
D103
D104
1N4148
1N4148
1N4148
D106
D107
D108
1N4148
1N4148
1N4148
R110
100
C106
47nF
CG-
R111
0
R112
100
CR
3 (C)
1 (B)
2 (E)
74
VE710s-4_VE710b-4
CR
C108
NC
R114
100
RED-
CG-
C107
47nF
RED+
R113
75
CG
C105
NC
GREENL103
0_0603
CB-
C104
47nF
GREEN+
CON13
CB
C109
47nF
CR-
CR-
10.3. Scaler (Realtek Scaler CPT Panel)
3DVCC
L106 200R
R3DVCC
L107 200R
2V5
P106
XO
X102
24.576MHz
RSDS_CON30
3DVCC
C145
22pF
C132
22uF_16V
C133 C134 C135 C136 C137 C138 C139
C140 C141 C142 C143
C144
100nF 100nF 100nF 100nF 100nF 100nF 100nF
100nF 100nF 100nF 100nF
P107
R158
1M
22uF_16V
C146
22pF
XI
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
AR1N
AR1P
R159
TMDS_AVCC
PLL_TEST1
PLL_TEST2
R160
R162
R161 1K
NC/4.7K
NC/4.7K
TMDS_AVCC
R163
4.7K
3DVCC
Near to Chip
L109 200R
C151 C152 C153 C154
100nF NC/100nF
100nF
9
12
14
15
17
18
20
21
23
24
TMDS_TST/PWM1
EXT_RES
RX2P
RX2N
RX1P
RX1N
RX0P
RX0N
RXCP
RXCN
11
13
19
26
10
16
22
25
TMDS_VDD
TMDS_VDD
TMDS_VDD
TMDS_VDD
TMDS_GND
TMDS_GND
TMDS_GND
TMDS_GND
NC/100nF
CB
CB-
CB
CB-
ADC_VCC
3DVCC
CG
CGCR
CR-
CG
CGCR
CR-
L110 200R
C159 +
C160 C161 C162
22uF_16V
100nF 100nF 100nF
100nF
29
36
41
ADC_VDD
ADC_VDD
ADC_VDD
C160.C161.C162IC
AHS
AVS
27
32
39
40
ADC_GND
ADC_GND
ADC_GND
ADC_GND
42
43
AHS
AVS
128
97
70
44
127
98
69
45
121
110
95
83
71
58
49
TCON7
TCON11
TCON10
TCON9
50
54
53
52
51
111
56
HSYNC
VSYNC
ADC_REFIO
108
107
106
105
104
103
102
101
100
99
AR1N
AR1P
AR2N
AR2P
AR3N
AR3P
AG1N
AG1P
AG2N
AG2P
BG3N
BG3P
BCLKN
BCLKP
BB1N
BB1P
BB2N
BB2P
BB3N
BB3P
68
67
66
65
64
63
62
61
60
59
BG3N
BG3P
BCLKN
BCLKP
BB1N
BB1P
BB2N
BB2P
BB3N
BB3P
AG3N/TEAN
AG3P/TEAP
ACLKN/TEBN
ACLKP/TEBP
AB1N/TECN
AB1P/TECP
AB2N/TECLKN
AB2P/TECLKP
AB3N/TEDN
AB3P/TEDP
94
93
92
91
90
89
88
87
86
85
AG3N
AG3P
ACLKN
ACLKP
AB1N
AB1P
AB2N
AB2P
AB3N
AB3P
BR1N/TOAN
BR1P/TOAP
BR2N/TOBN
BR2P/TOBP
BR3N/TOCN
BR3P/TOCP
BG1N/TOCLKN
BG1P/TOCLKP
BG2N/TODN
BG2P/TODP
82
81
80
79
78
77
76
75
74
73
AG1N
AG1P
VOLUME
AdjBACKLITE
AG2N
AG2P
AG3N
AG3P
ACLKN
ACLKP
AB1N
AB1P
AB2N
AB2P
AB3N
AB3P
L115
BG2N
BG2P
BG3N
BG3P
BCLKN
BCLKP
BB1N
BB1P
BB2N
BB2P
BB3N
BB3P
C158
100nF
C156
100uF/16V
BR1N
BR1P
BR2N
BR2P
BR3N
BR3P
BG1N
BG1P
BG2N
BG2P
R165
NC/0R 0805
R166
0R 0805
R170
0R 0805
0R 0805
C157
100nF
RN5
RSDS_CON50
I101
VA721(A)
VA521(A)
VA721(A)
R166,
R165,
R170
R198
0R 0805
NC
VA521(A)
R165
0R 0805
R166, R170
NC
R198 0R0603
RTD2023
RTD2013
8
7
6
5
1
2
3
4
YDIO
YCLK
BXDIO
POL
NC/22X4
22X4
R176 100/NC
TCON5 R193 22
XSTB
TCON1 R194 22
FXDIO
100/NC
1
2
3
4
C182C183
NC NC
VA521(A)
RN5, R193, R194
75
VE710s-4_VE710b-4
NC
YOEE
C184
R172 NC/22
XSTB
AR2N
R171 NC/22
CN1
NC
R195 22
AR2P
FXDIO
8
7
6
5
R177
YDIO
YCLK
BXDIO
POL
1
2
3
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
NC/0R 0603
YOE
8
7
6
5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
R198
RN6
TCON11
TCON10
TCON9
TCON7
BG1N
BG1P
VLCD_12V
AG2P
AG2N
AG1P
AR3P
RTD_RESET
BR3N
BR3P
YCLK
YDIO
YOEE
C155
47uF/16V
RTD_SCSB
DDC_CLK
BR2N
BR2P
FXDIO
XSTB
POL
BXDIO
RTD_SCLK
RTD_SDO_OR_SDI
DDC_DAT
BR1N
BR1P
VLCD
B+
BSOG/ADC_TEST
G+
GR+
R-
28
AR1N
AR1P/TCON[0]
AR2N/TCON[1]
AR2P/TCON[5]
AR3N/TCON[6]
AR3P/TCON[7]
AG1N/TCON[8]
AG1P/TCON[9]
AG2N/TCON[10]
AG2P/TCON[11]
RTD2023/2013
30
31
33
34
35
37
38
C163
2.5V Ground
2.5V Ground
2.5V Ground
2.5V Ground
6
7
4.7K/NC
2.5V Power
2.5V Power
2.5V Power
2.5V Power
DPLL_VDD
APLL_VDD
DPLL_GND
APLL_GND
113
112
55
TCON5
TCON1
100nF 100nF
VOLUME
VBRI
YOE
TCON[12]/COUT/PWM2
PWM0/REFCLK
TCON[13]/COUT/PWM2
TCON[11]/V[0]
TCON[10]/V[1]
TCON[9]/V[2]
TCON[8]/V[3]
TCON[7]/V[4]
TCON[6]/V[5]
TCON[5]/V[6]
TCON[1]/V[7]
TCON[0]/VCLK
4
5
3
8
C148 C149
AR3N
AR3P
I101
114
115
116
117
118
119
122
123
124
XO
XI
DDCSDA
DDCSCL
DDCSDA2
DDCSCL2
C147 +
22uF_16V
1
2
47
46
125
126
XO
XI
L108 200R
SCLK
SDIO[0]
TCON[4]/SDIO[1]
TCON[3]/SDIO2]
TCON[2]/SDIO[3]/PWM2
SCSB
RESET#
3DVCC
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3PVCC
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
120
109
96
84
72
57
48
AR2N
AR2P
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
VA721(A)
RN6, R171, R172 NC
NC
10.3. Scaler (Realtek Scaler CMO Panel)
VCC3V3
L106 200R
R3DVCC
L107 200R
2V5
XO
3DVCC
C145
22pF
X102
24.576MHz
C132
22uF_16V
C133 C134 C135 C136 C137 C138 C139
C140 C141 C142 C143
100nF 100nF 100nF 100nF 100nF 100nF 100nF
100nF 100nF 100nF 100nF
C144
+
R158
1M
22uF_16V
C146
22pF
XI
TMDS_AVCC
PLL_TEST1
PLL_TEST2
R160
R162
R161 1K
NC/4.7K
NC/4.7k
TMDS_AVCC
R163
4.7K
3DVCC
Near to Chip
L109 200R
C151 C152 C153 C154
100nF 100nF 100nF 100nF
CB
CBCG
CGCR
CR-
ADC_VCC
3DVCC
L110 200R
C159 +
C160 C161 C162
9
12
14
15
17
18
20
21
23
24
TMDS_TST/PWM1
EXT_RES
RX2P
RX2N
RX1P
RX1N
RX0P
RX0N
RXCP
RXCN
11
13
19
26
10
16
22
25
TMDS_VDD
TMDS_VDD
TMDS_VDD
TMDS_VDD
TMDS_GND
TMDS_GND
TMDS_GND
TMDS_GND
22uF_16V
100nF
100nF 100nF 100nF
C160.C161.C162 CLOSE TO IC
127
98
69
45
121
110
95
83
71
58
49
128
97
70
44
TCON[12]/COUT/PWM2
PWM0/REFCLK
TCON[13]/COUT/PWM2
113
112
55
AR1N
AR1P/TCON[0]
AR2N/TCON[1]
AR2P/TCON[5]
AR3N/TCON[6]
AR3P/TCON[7]
AG1N/TCON[8]
AG1P/TCON[9]
AG2N/TCON[10]
AG2P/TCON[11]
108
107
106
105
104
103
102
101
100
99
RXE0RXE0+
RXE1RXE1+
RXE2RXE2+
Volume
AdjBacklight
B+
BSOG/ADC_TEST
G+
GR+
R-
29
36
41
ADC_VDD
ADC_VDD
ADC_VDD
28
ADC_REFIO
27
32
39
40
ADC_GND
ADC_GND
ADC_GND
ADC_GND
42
43
AHS
AVS
RXO1RXO1+
RXO2RXO2+
RXOCRXOC+
BG3N
BG3P
BCLKN
BCLKP
BB1N
BB1P
BB2N
BB2P
BB3N
BB3P
68
67
66
65
64
63
62
61
60
59
AG3N/TEAN
AG3P/TEAP
ACLKN/TEBN
ACLKP/TEBP
AB1N/TECN
AB1P/TECP
AB2N/TECLKN
AB2P/TECLKP
AB3N/TEDN
AB3P/TEDP
94
93
92
91
90
89
88
87
86
85
RXE0RXE0+
RXE1RXE1+
RXE2RXE2+
RXECRXEC+
RXE3RXE3+
BR1N/TOAN
BR1P/TOAP
BR2N/TOBN
BR2P/TOBP
BR3N/TOCN
BR3P/TOCP
BG1N/TOCLKN
BG1P/TOCLKP
BG2N/TODN
BG2P/TODP
82
81
80
79
78
77
76
75
74
73
RXO0RXO0+
RXO1RXO1+
RXO2RXO2+
RXOCRXOC+
RXO3RXO3+
RXO3RXO3+
R167 0R
R168 NC
R169 NC
VLCD
CMO
M170E5-L05:
R167 0R
R168 169 NC
AU M170EN06:
R167 168 169
NC
HSD170ME13-A:
R167 168 169
0R
0.1uF
LVDS_CON30
VLCD
NC P107
RXO3RXOCRXO2RXO1RXO0RXE3RXECRXE2-
R3DVCC
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
C156
C155
47uF/16V
RXE1RXE0-
RTD_SCLK
RTD_SDO_OR_SDI
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
RXECRXEC+
RXE3RXE3+
RXO0RXO0+
50
54
53
52
51
111
56
HSYNC
VSYNC
AHS
AVS
I101
RTD2023 / 2013
30
31
33
34
35
37
38
C163
2.5V Ground
2.5V Ground
2.5V Ground
2.5V Ground
6
7
4.7K/NC
2.5V Power
2.5V Power
2.5V Power
2.5V Power
DPLL_VDD
APLL_VDD
DPLL_GND
APLL_GND
TCON[11]/V[0]
TCON[10]/V[1]
TCON[9]/V[2]
TCON[8]/V[3]
TCON[7]/V[4]
TCON[6]/V[5]
TCON[5]/V[6]
TCON[1]/V[7]
TCON[0]/VCLK
100nF 100nF
R159
114
115
116
117
118
119
122
123
124
4
5
3
8
C148 C149
DDCSDA
DDCSCL
DDCSDA2
DDCSCL2
C147 +
22uF_16V
XO
XI
47
46
125
126
L108 200R
1
2
SCLK
SDIO[0]
TCON[4]/SDIO[1]
TCON[3]/SDIO2]
TCON[2]/SDIO[3]/PWM2
SCSB
RESET#
3DVCC
XO
XI
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3.3V Power
3PVCC
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
3.3V Ground
120
109
96
84
72
57
48
P106
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
PVCC
PVCC
GND
RXO3RXOCRXO2RXO1RXO0RXE3RXECGND
RXE2GND
RXE1RXE0-
PVCC
GND
GND
RXO3+
RXOC+
RXO2+
RXO1+
RXO0+
RXE3+
RXEC+
GND
RXE2+
NC
RXE1+
RXE0+
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
CONN15x2 TO PANEL
R173
4.7K
R172
RTD_SCSB
RTD_RESET
100R
DDC_DAT
DDC_CLK
R176 100/NC
R177
100/NC
76
VE710s-4_VE710b-4
15'
P106 NC , P107 CONN15x2
17'
P106 LVDS_CON30 , P107 NC
RXO3+
RXOC+
RXO2+
RXO1+
RXO0+
RXE3+
RXEC+
RXE2+
RXE1+
RXE0+
10.5. MCU (Realtek Scaler CPT Panel)
VCPU
VCPU
3DVCC
3DVCC
R125
10K
C116
0R 0603
RN1
VCPU
RN2
100nF
12
IN4148
C121
22pF
C122
11
100nF
7
R128
R129
4K7
4K7
I105
1
2
3
4
A0
A1
A2
GND
I104
19
VCC
WP
SCL
SDA
8
7
6
5
R134
R135
100
100
24C16
MUTE
ST_DET1
LED_G
12V
VCC3V3
LED_O
R142
14
13
27
26
16
9
30
31
32
33
5
6
7
8
RN4
P5.0
P5.1
X1
P5.2
P5.3
P5.4
X2
P5.5
P5.6
RESET
DA8/HLFHO
DA9/HALFV
P1.0
P1.1
INT0/P3.2
P1.2
P1.3
P1.4
ISCL/P3.5/T1
P1.5
ISDA/P3.4/T0
P1.6
P6.0/AD0
P1.7
DA7
P6.1/AD1
P6.2
P4.0
P4.1
P6.3
P4.2
P6.4
P6.5
P3.1/TXD
P6.6
P3.0/RXD
P6.7
MTV312M64
VSS
C119
22pF
6
5
4
8
43
44
R127
1M
D114
RN3
10K X4
1
UP
DOWN
2
power
3
2
1
42
41
40
34
39
38
17
18
20
21
22
23
24
25
35
36
37
15
R130
10K X4
1K
onPanel_12V
R133
R136
VCC3V3
R138
WP
VCPU
onPanel_3V3
onBacklight
RTD_SCSB
RTD_SCLK
RTD_SDO_OR_SDI
R137
NC
NC
28
29
R140
R139
2K2
2K2
R143
R144
R145
9.09K
100
100
DDC_CLK
DDC_DAT
NC
R146
1K
NC
10
VCPU
NC
NC
VDD3
VCC
HSYNC
VSYNC
X101
12MHz
5
6
7
8
4
3
2
1
10uF/16V
10K X4
10K X4
C118
NC/10uF/16V
4
3
2
1
RTD_RESET
1
2
3
4
R132 100
C117
4
3
2
1
R199
2 Q101
MMBT3906
3
8
7
6
5
1K
5
6
7
8
R124
D113
IN4148
VCC3V3
10K
R148
3.32K
P701
8
7
6
5
4
3
2
1
Q102
MMBT3906 R149
4K7
1
P104
C123
1
2
3
4
5
6
7
8
R156
R155
R154
R153
100 2
100 down
up
100
1
100
R152
R151
R150
100 green
100 orange
100 power
PWR/SW
PSM/LED
PWR/LED
LED_O
2
DOWN
UP
1
Contral_key_pad
8 HEADER 2mm
VCC3V3
orange
NC
GREEN
ORANGE
VCC3V3
S701
CON8
Q103
MMBT3906
C131 C130 C129 C128 C126 C125 C127
NC/100p
NC/100p
NC/100p
NC/100p
NC/100p
NC/100p
NC/100p
2
1
R157
4K7
S705
LED_G
3
GREEN
C124
3 (C)
NC
1 (B)
77
VE710s-4_VE710b-4
2 (E)
S704
S703
S702
D701
10.5. MCU (Realtek Scaler CMO Panel)

VCPU
VCC3V3
VCPU
RTD_RESET
1K
D115
1
2 Q101
MMBT3906
3
1N4148
R123
1K
C116
R125
0
RN1
RN2
100nF
C117
11
R128
R129
4K7
4K7
100nF
I105
19
8
7
6
5
VCC
WP
SCL
SDA
WP
R134
R135
100
100
24LC16
MUTE
ST_DET1
LED G
LED O
VCC3V3
14
13
27
26
16
9
30
31
32
33
MTV312M64
5
6
7
8
R121
10K
10K
VCPU
R137
NC
NC
R140
R139
2K2
2K2
R144
R145
10K
R141
VCC3V3
9.03K
Q102
R147
3.32K
MMBT3906 R149
4K7
1
LED_O
3
C123
orange
NC
P104
R156
R155
R154
R153
1
2
3
4
5
6
7
8
R152
R151
R150
100 select
100 down
up
100
menu
100
VCC3V3
3 (C)
Q103
MMBT3906
100 green
100 orange
100 power
2
1
R157
4K7
3
GREEN
CON8
C124
NC
C131 C130 C129 C128 C126 C125 C127

NC
NC
NC
NC
NC
NC
NC
78
VE710s-4_VE710b-4
onPanel_3V3
onBacklight
RTD_SCSB
RTD_SCLK
RTD_SDO_OR_SDI
VCC3V3
R143
12V
1K
WP
R138
R171
10K X4
R122
R133
28
29
VSS
C122
10
12
C121
22pF
RN4
menu
UP
DOWN
select
power
3
2
1
42
41
40
34
39
38
17
18
20
21
22
23
24
25
35
36
37
15
P5.0
P5.1
P5.2
X1
P5.3
P5.4
P5.5
X2
P5.6
DA8/HLFHO
RESET
DA9/HALFV
P1.0
P1.1
P1.2
INT0/P3.2
P1.3
P1.4
ISCL/P3.5/T1
P1.5
ISDA/P3.4/T0
P1.6
P6.0/AD0
P1.7
DA7
P6.1/AD1
P6.2
P4.0
P4.1
P6.3
P4.2
P6.4
P6.5
P6.6
P3.1/TXD
P3.0/RXD
P6.7
4
3
2
1
I104
6
5
4
8
43
44
C119
22pF
NC
NC
VDD3
VCC
HSYNC
VSYNC
R127
1M
VCPU
1
2
3
4
4
3
2
1
C118
NC/10uF/16V
X101
12MHz
A0
A1
A2
GND
VCC3V3
10K X4
10K X4
10uF/16V
1
2
3
4
8
7
6
5
R124
5
6
7
8
D113
1N4148
1 (B)
LED_G
2 (E)
100
100
DDC_CLK
DDC_DAT
10.6. Inverter (CPT CLAA170EA08QV /CMO M170E5-/L09 Panel)

F901
P901
JP
VCC12V
I902
78L05(3.3V)
NC(5V)
C911
22pF/3KV/DIP(CPT.CMO)
10PF/3KV/DIP(HS)
+
C902
0.1uF/DIP
C903
470uF 16V
IN Out
GND
1
C931
5pF/3KV/DIP
R906
10K 1%(3.3V)/DIP
33K 1%(5V)
2
P902
T901
1
R903
10 (5V)
NC(3.3V)/1206
5V
R943
1.5M.3KV
DIP
C930
330p
DIP
3
D915
NC
R932
10
DIP
R905
22K 1%/DIP
6
10
EEL-19
R917
10
1206
Q904
2N7002K
SOT-23
Q910
2N7002K
SOT-23
R944
2K 1%
DIP
D913
1N4148/DIP
R945
274
1206
R941
274
1206
1N4148
SMD
C923
6.8nF
DIP
C905
R921
D908
681 1%
DIP
C926
D902
1N4148/DIP
Brightness
Q906
AP9977J
+
R907
13K 1%/1206
18K 1%(3.3V)
C901
22uF 50V
R911
5.1M
1206
I901
1
R910
NC
2
J950
JUMPER
3
R909 100
DIP
ON/OFF
4
Q902
KSC945
C925
0.1UF DIP
R901
10K
1206
DIM
GNDA VDDA
CT
DRV2
DRV1
D922
1N4148
DIP
1
2
R947
1.5M.3KV
DIP
C916
22P,3KV
CPT/CMO
10PF/3KV
HS/DIP
P904
DIP
R918
1M
1206
+
C932
5P,3KV
DIP
C910
470uF 16V
Q903
NC
C933
330p
DIP
T902
1
C909
330PF
DIP
D911
D914 1N4148 1N4148/SMD
DIP
Q911
2N7002K
SOT-23
C915
0.01uF
DIP
C907
0.047uF
DIP
C908
47PF
DIP
DIP
R939
82.5 1%(CPT)
33.2 1%(CMO)
75 1%(HS)
1206
P903
D906 1S4
DIP
OZ9932D
ISEN
SST
C914
0.068uF
DIP
R922 5.1K D905 1N4148

1206
DIP
D904
1N4148
DIP
C920
0.1uF/DIP
R923
IN4148 SMD
3920 1%(CPT/CMO)
2740 1% (HS)
C921
0.1UF/DIP
D921
1N4148
DIP
Q907
AP9977J
C906
22uF/50V
R930
1M/1206
D903
1N4148
DIP
1000PF/DIP
1000PF/DIP
D907
7
C922
6.8nF
DIP
Q905
2N7002K
SOT-23
R942
274
1206
R948
2K 1%
DIP
1
2
R946
274
1206
D912
1N4148
SMD
C924
0.1uF
DIP
R931
1M
1206
R927
681. 1%
DIP
3
Q908
AP9977J
C904
1000PF
DIP
R916
10
DIP
10
EEL-19
R933 C927
10 1000PF
DIP
DIP
R926 5.1K
D909 1N4148 SMD
1206
R928
3920 1%(CPT/CMO)
2740 1% (HS)
1206
D910
EP05Q04
SMD
Q909
AP9977J
D916
NC
C919
0.068uF
DIP
R940
82.5 1%(CPT)
33.2 1%(CMO)
75 1%(HS)
1206
.DP46
79
VE710s-4_VE710b-4
10.7. A-D Power (CPT CLAA170EA08QV /CMO M170E5-L09 Panel)

R820
22 1/2W
DIP
D804 2A07
100K/1206
R833
R835
C820
1000PF/1KV
DIP
100K/1206
D803 2A07
100K/1206
100K/1206
R834
+
D802 2A07
C813
0.01UF
500V
C805
100uF
400V
R839
C806
1000PF/1KV
DIP
NC
R836
L803
5.2uH
D821 SRF10120
D806 BYV26C
D805
NC
911K/DIP 1/2S
C823
470uF/25V
7,8
Brightness
R844
D801 2A07
ON/OFF
R806
511K/1206
R839
L806
910K /1206
L807
JP
R851
(R851)
(39K TO
5V1206)
R804
511K/DIP 1/2S
R803
1M /1206
I801
1
C804
NC
L805
ET-20
C810
33uF/50V
D809
IN4148/DIP(3.3V)
1N4148(5V)
1S4(option)
+
C809
10uF/50V
GND Driver
FB
VDD
VIN
Sense
RI
RT
R805
910K
1206
Q801
L801
BEAD
R852
(10K)
1206
D808
30V(3.3V)
30V(5V)
27V(OPTION)
C811
1000P/DIP
L808
3T
D812
R811
0.62/ 2W
(0.68/2W)
(VA721)
OPTION
NC
1
Q803
MMBT3904
SMD
1K/DIP
2K(5V)
Q804
MMBT3906
SMD
R840
3K/DIP
R828
R830
2.2K 1%(5V)
1.18K 1%
DIP
Q802
MNMBT2907A/SMD
C826
I803
4700PF/DIP
TL431D
C845
0.1uF/50V
DIP
R824
24.9K 1%(5V)/1206
8.25K 1% (3.3V)
R826
5.6K
1206
D813
R809
47R/1206
R845
3.65K 1%
DIP
1/1W
R842
1206
12V
NC
ON/OFF
DIM
5V/3.3V
5V/3.3V
GND
Mute
Volume
GND
P802
R847
R823
1K/DIP
10
9
8
7
6
5
4
3
2
1
R846
2K/DIP
R821
10 1/2W
C821
DIP
1000PF/1Kv
DIP
R832
1K/1206
I802
TLP621
C802
C831
4700PF
1N4148/DIP
180P/DIP
F801
T2.5A/250V
C803
4700pF
470uF 16V
JUMPER
C824
R816
+ 1000UF
681/1206
10V
D822
SR306
(OPTION)
C808
L802
3T
L804
R807
39/1206
C801
0.47uF
R808
133K 1%/1206
C825
NC
D823
T801
ER28
C807
0.1uF
LD7552
11,12
AP03N70F-A
R812
1M /1206
D807
1U4G
NC
R802
10 3A
511K/1206 R843
bead
R801 NA
C822
1500uF/16V
10
4
12V
5V / 3.3V
R831
110K 1%
R825
13K 1%
1206
1N4148/DIP
4700pF
C812
10000P/DIP
C839
FG
.DP46
1uF/50V
S801
AC IN 100~240V
80
VE710s-4_VE710b-4
11.1. MAIN PCB TOP VIEW (Realtek Scaler CPT Panel)
11.1. MAIN PCB TOP VIEW (Realtek Scaler CMO Panel)
81
VE710s-4_VE710b-4
11.2. MAIN PCB BOTTOM VIEW (Realtek Scaler CMO Panel)
11.2. MAIN PCB BOTTOM VIEW (Realtek Scaler CPT Panel)
82
VE710s-4_VE710b-4
11.3. CON PCB TOP VIEW
11.4. CON PCB BOTTOM VIEW
83
VE710s-4_VE710b-4
11.5. POWER PCB TOP VIEW (CPT CLAA170EA08QV / CMO M170E5-L09 Panel)
84
VE710s-4_VE710b-4
11.6. POWER PCB BOTTOM VIEW (CPT CLAA170EA08Q / CMO M170E5-L09 Panel)
* Readers Response*
Dear Readers:
Thank you in advance for your feedback on our Service Manual, which allows continuous improvement
of our products. We would appreciate your completion of the Assessment Matrix below, for return to
ViewSonic Corporation.
Assessment
A. What do you think about the content of this Service Manual?
Unit
Excellent
Good
Fair
Bad
1. Precautions and Safety Notices

2. Specification
3. Front Panel Function Control Description
4. Circuit Description
5. Adjustment Procedure
6. Troubleshooting Flow Chart
7. Recommended Spare Parts List
8. Exploded Diagram and Exploded Parts List
9. Block Diagrams
10. Schematic Diagrams
11.PCB Layout Diagrams
B. Are you satisfied with this Service Manual?

Item
Excellent
Good
Fair
Bad
1. Service Manual Content

2. Service Manual Layout
3. The form and listing
C. Do you have any other opinions or suggestions regarding this service manual?
Readers basic dada:
Name:
Title:
Company:
Add:
Tel:
Fax:
E-mail:
After completing this form, please return it to ViewSonic Quality Assurance in the USA at facsimile
1-909-839-7943. You may also e-mail any suggestions to the Director, Quality Systems & Processes
(marc.maupin@viewsonic.com)
85
VE710s-4_VE710b-4

Service Manual: Viewsonic Ve710B-4 Ve710S-4

Încărcat de

Informații document

Descriere originală:

Titlu original

Drepturi de autor

Formate disponibile

Partajați acest document

Partajați sau inserați document

Opțiuni de partajare

Vi se pare util acest document?

Este necorespunzător acest conținut?

Drepturi de autor:

Formate disponibile

Service Manual: Viewsonic Ve710B-4 Ve710S-4

Încărcat de

Drepturi de autor:

Formate disponibile

Service Manual

(VE710s-4_VE710b-4_SM Rev. 1a Jun. 2006)

Precautions and Safety Notices

Front Panel Function Control Description

Troubleshooting Flow Chart

Recommended Spare Parts List

Exploded Diagram and Exploded Parts List

10. Schematic Diagrams

11. PCB Layout Diagrams

1. Precautions and Safety Notices (VE710s-4/VE710b-4)

1.2. PRODUCT SAFETY NOTICE

1.3. SERVICE NOTES

2.1. PRODUCT SPECIFICATIONS

Energy Star compliant VESA

SXGA 1280 1024 (max.)

LCD Display Color

262K Color. (6bit)

450 : 1 (typ.) 360:1 (min.)

230 cd/ m (min.)

300 cd/m (typ.)

Active Display Area

UL, CUL, TV, CE, FCC, VCCI, BSMI,CCC, Energy Star.

Input Voltage: 100~240 Vac

2.2. FACTORY SUPPORTING MODES

VESA 1280 x 1024 @ 60Hz

Look up table timing:

1. 640 x 350 @ 70Hz, 31.5kHz

10. 800 x 600 @ 75Hz, 46.9kHz

2.3. D-SUB CONNECTOR

D-SUB 15 PIN CONNECTOR

TTL positive or negative

TTL positive or negative

3. Front Panel Function Control Description

Front Control Panel

Displays the control

Scrolls through menu options and

Displays the Main Menu

Also a shortcut to display the

Do the following to adjust the screen image:

To display the Main Menu, press button [1].

NOTE: All OnView menus and adjustment screens disappear automatically

To highlight a control you want to adjust, press I or J to scroll up or down

To adjust the control, press the up I or down J buttons.

The following tips may help you optimize your display:

Main Menu Controls

video signal to eliminate waviness and distortion.

(black level) and the foreground (white level).

sRGB sRGB is quickly becoming the industry standard for color

management, with support being included in many of the latest

in most office settings with fluorescent lighting).

To select color (R, G or B) press button [2].

Information displays the timing mode (video signal input)

coming from the graphics card in your computer. See your

The Image Adjust controls are explained below:

screen image. You can toggle between Horizontal and Vertical

Setup Menu displays the menu shown below.

The Setup Menu controls are explained below.

the menus and control screens.

OSD Position allows you to move the on-screen display menus

screen is displayed. For example, with a 15 second setting, if

OSD Background allows you to turn the On-Screen display

settings if the display is operating in a factory Preset Timing
