Universitatea Politehnica Bucuresti

Facultatea de Transporturi
Specializarea Telecomenzi si Electronica in Transporturi

PROIECTARE ASISTATA DE CALCULATOR

Oscilator comandat in current (OCC) cu 4011
-proiect-

Student: Totea Marius-Alexandru

Grupa: 8314
 Cuprins

1. Lucrarea si schema in multisim

2. Fisierul .cir in Spice
3. Listarea fisierului .out
4. Graficele corespunzatoare analizelor
5. Cablajul imprimat
1.Lucrarea
Schema in multisim
2. Fisierul .cir in Spice

*Oscilator_comandat_in_curent
V1 7 0 5V
C1 0 6 100n
R1 1 0 1k
U1A NAND(2) $G_DPWR $G_DGND 1 1 5
+T_NODELAY IO_STD
U1B NAND(2) $G_DPWR $G_DGND 5 5 6
+T_NODELAY IO_STD
D1 4 0 DINT
D2 0 2 DINT
D3 5 2 DINT
D4 4 5 DINT
Q1 2 7 4 BC557A
Q2 7 7 2 BC557A
.MODEL T_NODELAY UGATE
.MODEL D1N4148 D (IS=0.1PA, RS=1.6 CJO=2p TT=12n BV=100 IBV=0.1P)
.MODEL BC557A PNP(BF=100)
.MODEL DINT D
.LIB "eval.lib"
.LIB "dig_io.lib"
.TRAN 1mS 10S
.DC V1 5V 10V 4V
.TF V(1)V1
.PRINT DC V(1)I(R1)
.PROBE
.END
3. Listarea fisierului .out
SMALL-SIGNAL CHARACTERISTICS
V(1)/V1 = 0.000E+00
INPUT RESISTANCE AT V1 = 8.249E+11
OUTPUT RESISTANCE AT V(1) = 2.811E+02
****INITIAL TRANSIENT SOLUTION TEMPERATURE = 27.000 DEG C
NODE VOLTAGE NODE VOLTAGE NODE VOLTAGE NODE
VOLTAGE
( 1) 1.3188 ( 2) 2.3081 ( 4) .1501 ( 5) 1.3836
( 6) 1.3499 ( 7) 5.0000 ($G_DGND) 0.0000
($G_DPWR) 5.0000 (X$1_AtoD1.1) 1.4068
(X$1_AtoD1.2) .7034 (X$1_AtoD1.3) 2.1185
(X$1_AtoD2.1) 1.4068 (X$1_AtoD2.2) .7034
(X$1_AtoD2.3) 2.1185 (X$5_AtoD1.1) 1.4647
(X$5_AtoD1.2) .7324 (X$5_AtoD1.3) 2.1774
(X$5_AtoD2.1) 1.4647 (X$5_AtoD2.2) .7324
(X$5_AtoD2.3) 2.1774

DGTL NODE : STATE DGTL NODE : STATE DGTL NODE : STATE DGTL
NODE : STATE
( 1$AtoD2) : X ( 5$DtoA) : X ( 6$DtoA) : X ( 5$AtoD2) : X
( 1$AtoD) : X ( 5$AtoD) : X

VOLTAGE SOURCE CURRENTS

NAME CURRENT
V1 -5.459E-12
X$DIGIFPWR.VDPWR -6.550E-02
X$DIGIFPWR.VDGND -1.324E-03

TOTAL POWER DISSIPATION 3.28E-01 WATTS

4. Graficele corespunzatoare analizelor
5. Cablajul imprimat
